Safety Product Mechanical
Information Information Installation

Table 14-2 Maximum continuous output current (400V drives)

Model FLC (A)
BA1401 2.8
BA1402 3.8
BA1403 5.0
BA1404 6.9
BA1405 8.8
BA1406 11
BA2401 15.3
BA2402 21
BA2403 29

Table 14-3 Maximum continuous output current (575V drives)

Model FLC (A)
BA3501 5.4
BA3502 6.1
BA3503 8.3
BA3504 11

Table 14-4 Maximum continuous output current (690V drives)

Model FLC (A)
BA4601 22
BA4602 27
BA4603 36
BA4604 43
BA4605 52
BA4606 62
14.5

Safety label

The safety label supplied with the connectors and mounting brackets
must be placed on a fixed part inside the drive enclosure where it can be
seen clearly by maintenance personnel for UL compliance.
The label clearly states "CAUTION Risk of Electric Shock Power down
unit 10 minutes before removing cover".
14.6

UL listed accessories

• BA-Keypad
• SM-Ethernet
• SM-I/O Lite
• SM-I/O 120V
• SM-LON
• SM-I/O Plus
• SM-CAN
• SM-INTERBUS
• SM-Applications
• SM-Applications Lite V2
Affinity User Guide
Issue Number: 5
Electrical Getting Basic Running
Installation Started parameters the motor
Model FLC (A)
BA3401 35
BA3402 43
BA3403 56
BA4401 68
BA4402 83
BA4403 104
BA5401 138
BA5402 168
BA6401 205
BA6402 236
Model FLC (A)
BA3505 16
BA3506 22
BA3507 27
Model FLC (A)
BA5601 84
BA5602 99
BA6601 125
BA6602 144
• SM-DeviceNet
• SM-PROFIBUS-DP-V1
• SM-I/O PELV
• SM-I/O 24V Protected
• SM-I/O 32
• SM-Applications Plus
• SM-I/O Timer
• SM-Applications Lite
• SM-CANopen
• SM-EtherCAT
www.controltechniques.com
SMARTCARD
Optimization PC tools
operation
Advanced Technical
Diagnostics
parameters Data
UL Listing
Information
265
