I/O Module
The I/O module (Part No. 9155034) is one of the
elements and is used for extending the number of inputs and outputs.
The module contains two
These two connectors are fully interchangeable and can be used both as inputs
from the main unit and outputs to other modules.
If this module is the last one on the bus, one of the connectors remains
unconnected.
The module package includes an 80 mm long interconnecting cable.
The inputs / outputs are addressed as follows: <module_name>.<input
/output_name>
Module name parameter in the Hardware / Extenders menu.
RELAY1 RELAY1 terminals with accessible 30 V / 1 A AC/DC NO/NC contact
RELAY2 RELAY2 terminals with accessible 30 V / 1 A AC/DC NO/NC contact
IN1 IN1 terminals for input in passive/ active mode (−30 V to +30 V DC)
OFF = open OR U
2N TELEKOMUNIKACE a.s., www.2n.cz
with iOS 8 and higher
®
2N Helios IP Verso
, e.g. module5.relay1. The module name is configured in the
> 1.5 V
IN
®
2N Helios IP Verso
bus connectors.
