4. Pull the bus using the cable bushing available in the flush mounting box.
Main Unit
Power Supply Connection
®
2N Helios IP Verso
directly from the LAN equipped with PoE 802.3af supporting network elements.
Owing to different power outputs, the power supply selection affects the maximum
count and applicability of the modules connected of the main unit.
External power supply
Use a 12 V ±15 % SELV supply dimensioned to the minimum current consumption of 2
A (Part No. 91341481E) to make your system work reliably. This power supply provides
®
2N Helios IP Verso
PoE Power Supply
®
2N Helios IP Verso
and can be fed directly from the LAN via the compatible network elements. If your
LAN does not support this technology, insert a PoE injector, Part No. 91378100,
®
between 2N Helios IP Verso
®
provides 2N Helios IP Verso
modules.
Combined Power Supply
®
2N Helios IP Verso
time. In this configuration, the maximum power for the connected modules is
available.

LAN Connection

®
2N Helios IP Verso
cable (Cat 5e or higher) terminated with an RJ-45 (LAN) connector. As the device is
equipped with the Auto-MDIX function, both the straight and crossed cable can be
used.
2N TELEKOMUNIKACE a.s., www.2n.cz
can be powered either from an external 12 V / 2 A DC source or
with 24 W for feeding of the main unit and connected modules.
is compatible with the PoE 802.3af (Class 0–12,95 W) technology
and the nearest network element. This power supply
with 12 W for feeding of the main unit and connected
can be fed from an external power supply and PoE at the same
is connected to the Local Area Network (LAN) via the UTP/STP
