Technical Data

15.1 Technical data MDH 860

MDH 860 - mbNet.mini with WAN
• 1x WAN
• 3x LAN (3-port switch)
• 1x USB host
• 2x digital input
• Connection only possible to the portal
(mbCONNECT24, mymbCONNECT24.hosted, -.mini, -.midi, -.maxi, -.virtual)
MDH 860
DC voltage
Power (at 24 V)
Protection class
Pollution degree
Area of application
Altitude
Operating temperature range
Operating temperature range HW1*
Storage temperature range
Storage temperature range HW1*
Humidity
Weight
Dimensions
LAN interface (x 3)
WAN interface
Inputs (x 2)
VPN
General certificates
Country of application
Page 86 of 90 | Version: 1.6.0 DR 03 (10.01.2017) - EN | 10.01.2017
10 - 30 V DC (SELV and Limited Energy circuit)
max. 250 mA
IP 20
2
Dry environments
Up to 2000 m
0...+50 °C
-20...+75 °C
-20...+60 °C
-40...+90 °C
0...95% (non-condensing)
230 g
69 mm x 25 mm x 85 mm (W x D x H)
10/100MBit/s full- and half-duplex mode, automatic recognition, patch cable /
crossover cable
10/100MBit/s full- and half-duplex mode, automatic recognition, patch cable /
crossover cable
Low 0-3,2 V, high 8-30 V
Open VPN - connection only possible to the portal (mbCONNECT24, mymb-
CON-NECT24.hosted, -.mini, -.midi, -.maxi, -.virtual)
EN 61000-6-4:2011-9, EN 61000-6-2:2006-3
World wide
* Hardware version 1 - a reference to the hardware version can be found on the device rating plate.
