- Page 1 ZS500 Instructi ons for installati on and use English More documents on: www.zodiac-poolcare.com H0430700.E - 2016/01...
- Page 2 WARNINGS • Failure to respect the warnings may cause serious damage to the pool equipment or cause serious injury, even death. • The appliance is intended for a specifi c pool use and must not be used for any use other than that for which it was designed.
-
Page 3: Table Of Contents
It is prohibited to distribute or modify this document in any way without authorisati on from • Zodiac®. Zodiac® is constantly developing its products to improve their quality; therefore, the • informati on contained in this document may be modifi ed without noti ce. -
Page 4: ❶ Installati On
❶ Installati on 1.1 I Selecti ng the locati on • The device must be installed at a minimum distance from the pool's surrounding edge. This distance is determined by the electrical standards which apply in the installati on country. •... -
Page 5: I Hydraulic Connecti Ons
1.2 I Hydraulic connecti ons • The device will be connected with a Ø50 PVC pipe, using the half union connectors supplied (see § “5.1 I Descripti on”), to the pool's fi ltrati on circuit, aft er the fi lter and before the water treatment. •... -
Page 6: I Electricity Supply Connecti Ons
1.3 I Electricity supply connecti ons • Do not disconnect the electricity supply when the device is running. If the electric power supply is interrupted, wait a minute before restoring the power. • Means for disconnecti on from the supply mains having a contact separati on in all poles that provide full disconnecti on under overvoltage category III, must be incorporated in the fi... -
Page 7: I Opti On Connecti Ons
1.4 I Opti on connecti ons Connecti ng the "Heati ng priority", "On/off command" and "Alarm" opti ons: • Any incorrect connecti on to terminals 1 to 12 may damage the device and cancel its warranty. • Under no circumstances should the fi ltrati on pump motor be supplied via terminals 11-12. •... -
Page 8: ❷ Use
❷ Use 2.1 I Operati ng principle Your heat pump uses the calories (heat) in the air to heat up your pool’s water. The process to heat your pool’s water to the temperature you want may take a few days as it depends on the weather conditi ons, your heat pump’s power and the diff... -
Page 9: I Operati Ng
2.3 I Operati ng • Check that there are no tools or other foreign objects in the machine. • The panel that provides access to the technical secti on must be put in place. • Set the valves as follows: valve B wide open, valves A, C, D and E closed. : water entry valve : by-pass valve : water exit valve... -
Page 10: I User Functi Ons
2.4 I User functi ons 2.4.1 Adjusti ng the temperature set point: • Press to increase the temperature by 0.5 °C, • Press to reduce the temperature by 0.5 °C. The heat pump stops automati cally when the pool reaches the required temperature. 2.4.2 Using the diff... -
Page 11: I Presentati On Of The Menu
2.5 I Presentati on of the menu To access the menu, press To browse the menus and modify the values, press To validate a selecti on, press To go back in the menus, press Select the language for the interface Set the current day and ti me For faster heati ng For opti mised operati on... -
Page 12: ❸ Maintenance
❸ Maintenance 3.1 I Wintering • Wintering is vital to prevent the condenser breaking due to freezing. This is not covered by the warranty. • To avoid damaging the equipment with condensati on, do not fully cover it; a wintering cover is provided. -
Page 13: ❹ Troubleshooti Ng
❹ Troubleshooti ng • Before you contact your reseller, please carry out these few simple checks using the following tables if a problem occurs. • If the problem conti nues contact your reseller. • : Acti ons reserved for a qualifi ed technician 4.1 I Device behaviour •... -
Page 14: I Error Code Display
4.2 I Error code display Display Possible causes Soluti ons Resetti ng Error 01 Check the RJ11 and RJ45 Bad connecti on between the A1 Automati c (if fewer connectors on the link cable between and A2 boards than 4 faults per Communicati on the boards fault between the... -
Page 15: I Additi Onal Menus
Display Possible causes Soluti ons Resetti ng Error 12 Sensor is faulty or offl ine (J13 ST5 sensor error Reconnect or change the sensor Press connector) compressor discharge sensor Error 13 Sensor is faulty or offl ine (J16 ST4 sensor fault fl uid line Reconnect or change the sensor Press connector) sensor... -
Page 16: I Wiring Diagrams
4.4 I Wiring diagrams 4.4.1 ZS500 MD4-MD5-MD8 H0430700.E - EN - 2016-01... - Page 17 4.4.2 ZS500 TD5-TD8 H0430700.E - EN - 2016-01...
-
Page 18: ❺ Specifi Cati Ons
❺ Specifi cati ons 5.1 I Descripti on ZS500 Ø50 connector to be glued (x2) Condensati on evacuati on kit (Ø18) Wintering cap (x2) Wintering cover Heati ng priority Kit for remote control Plant room kit Condensate pan PAC NET... -
Page 19: I Technical Specifi Cati Ons
5.2 I Technical specifi cati ons ZS500 -12 to 40 °C Operati ng temperature range water 12 to 32 °C Voltage 220-240V-50Hz 220-240V-50Hz 380-415V-50Hz 220-240V-50Hz 380-415V-50Hz Acceptable variati on in voltage ± 6 % (during operati on) Polluti on class... - Page 20 Votre revendeur Your retailer Modèle appareil Appliance model Numéro de série Serial number Trouvez plus d’informations et enregistrez votre produit sur More informations and register you product on www.zodiac-poolcare.com ZODIAC® is a registered trademark of Zodiac International, S.A.S.U., used under license.
Need help?
Do you have a question about the ZS500 and is the answer not in the manual?
Questions and answers
Zodiac ZS500. All set up and there is electricity to the machine because the display is lit up, but the fan will not come on. The display reads 'Error Code 3 over current'. Help
'Error Code 3 over current' on the Zodiac ZS500 indicates a problem with the electrical network, such as:
- Incorrect earthing
- Power supply interruption
- Voltage drop
- Overvoltage
To resolve it:
1. Check that the earth cables are correctly connected.
2. Check the quality of the electrical network.
The protection is automatic if there are fewer than 4 faults per hour.
