- Page 1 Technical room Kit - ZS500, Z550 iQ Spare Parts/Accessories Instructions Manual - English Translation of the original instructions in french H0493400.C - 2021-07...
- Page 2 Only a person qualified in the technical fields concerned (electricity, hydraulics or refrigeration) is authorised to perform this procedure. The qualified technician working on the appliance must use/wear personal protective equipment (such as safety goggles and protective gloves, etc.) in order to reduce the risk of injury occurring when working on the appliance.
-
Page 3: Final Layout
Final layout For the best results, make sure that the duct is as straight as possible (avoid elbow joints and chicanes). Do not extend the duct (3,3 meters maximum). The aspiration and blowing grills must be at least 1.5 metres apart to avoid recycling the air. Installing the external grills Seal the grill frame on the external wall of the technical Attach the grill to the frame of the external wall of... - Page 4 Reposition the cover and attach it to the Position the duct on the frame and secure it using the 4 self-boring screws frame on the heat pump using the 4 long provided (there are holes in the duct framework). screws and washers provided. Run the metal cable into the tensioner (following the arrow) then into the plastic duct.
- Page 5 Use the following table to configure the appliance, depending on its model. ZS500 Z550 iQ Press and hold for 3 seconds to access the advanced settings. Enter the menu by pressing the key: • Select “CODE“ using the arrows. • Press to confirm.
