SITE TECHNICAL DOCUMENTATION
GSM 900/1800 - myX-3 & myX-5
Doc. No. :
Version :
Date :
2, rue du Petit Albi, 95800 Cergy Saint-Christophe, France
Tel (33) 1 30 73 50 50 - Fax (33) 1 30 73 50 55
Cergy Saint-Christophe, France
SCT U38 SSC DTS 009
B
December 12 , 2002
Produced by
Copyright © 2002
SAGEM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the myX-5 and is the answer not in the manual?

Questions and answers

Related Manuals for Sagem myX-5

Summary of Contents for Sagem myX-5

  • Page 1 SITE TECHNICAL DOCUMENTATION GSM 900/1800 - myX-3 & myX-5 Doc. No. : SCT U38 SSC DTS 009 Version : Date : December 12 , 2002 Produced by 2, rue du Petit Albi, 95800 Cergy Saint-Christophe, France Tel (33) 1 30 73 50 50 - Fax (33) 1 30 73 50 55 Copyright ©...
  • Page 2 Technical Site Documentation - GSM 900 / 1800 myX-3 & myX-5 NON DISCLOSURE AGREEMENT This document is SAGEM SA property. It can not be copied or communicated in all or part without written authorisation. Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002...

  • Page 3: Table Of Contents

    Technical Site Documentation - GSM 900 / 1800 myX-3 & myX-5 CONTENTS CHAPTER 1 - FOREWORD 1.1 HOW TO USE THE SITE TECHNICAL DOCUMENTATION.............1-1 1.2 ABREVIATIONS ..........................1-2 1.3 COMMENTS SHEET..........................1-3 CHAPTER 2 - DESCRIPTION - OPERATION 2.1 REMINDERS ABOUT THE GENERAL CHARACTERISTICS OF GSM AND PCS NETWORKS..2-1 2.2 REMINDERS ABOUT THE CHARACTERISTICS OF myX-3 &...
  • Page 4 Technical Site Documentation - GSM 900 / 1800 myX-3 & myX-5 SYMPTOM SHEET 04 : DISPLAY…………………………….…………………………………………….. 3-14 SYMPTOM SHEET 05 : KEYPAD…..………….………………………………………………………………3-15 SYMPTOM SHEET 06 : RING TONES.……………………………………………………………………… 3-16 SYMPTOM SHEET 07 : VIBRATE…………………………………………………. 3-17 SYMPTOM SHEET 08 : MICROPHONE / LOUDSPEAKER……………………………………………… 3-18 CHAPTER 4 - TESTS AND CHECKS 4.1 GENERAL ABOUT TESTS ........................4-1...
  • Page 5 Technical Site Documentation - GSM 900 / 1800 myX-3 & myX-5 LEVEL 1 MAINTENANCE…………………………………………………………………………………… ..5-13 PROCEDURE SHEET 1 02 : REMOVING AND REPLACING THE DISPLAY……. 5-14 PROCEDURE SHEET 1 03 : REMOVING AND REPLACING THE LIGHT GUIDE KEYPAD…………. 5-16 PROCEDURE SHEET 1 04 : REMOVING AND REPLACING THE ELECTRONIC BOARD….……… 5-18 PROCEDURE SHEET 1 05 : REMOVING AND REPLACING THE METAL DOME..…………………..
  • Page 6 Technical Site Documentation - GSM 900 / 1800 myX-3 & myX-5 CHAPTER 7 – TECHNICAL INFORMATION BULLETIN 7.1 PURPOSE ............................7-1 7.2 APPLICATION ............................7-1 CHAPTER 8 – ILLUSTRATED PARTS CATALOG 8.1 myX-3 SPARE PARTS ........................8-1 8.2 myX-5 SPARE PARTS ........................8-3 APPENDIX 1 – COMPOSITION TABLE Ref.

  • Page 7: Chapter 1 - Foreword

    These sheets are updated from time to time in Technical Information Bulletins (TIB). The information contained in this document is non-contractual, since phone characteristics can change. Phones are managed based on SAGEM handset codes; any order for spare parts must refer to these codes (typical code 25 xxx xxx-x).

  • Page 8: Abreviations

    Chapter 5: Maintenance procedures, contains level 0 to 2 maintenance procedures to be carried out on the equipment, and the procedure to return to SAGEM level 3. Chapter 6: Accessories, describes the characteristics of accessories for myX-3 & myX-5 phones . Chapter 7: Technical Information Bulletins, contains the various modifications made to this documentation.

  • Page 9: Comments Sheet

    Technical Site Documentation - GSM 900 / 1800 myX-3 & myX-5 Subscriber Identify Module Short Message Service SMS MT Short Service Message Mobile Terminating SMS MO Short Service Message Mobile Originating SMS CB Short Service Message Cell Broadcast TDMA Time Division Multiple Access...

  • Page 10: Date : December

    Technical Site Documentation - GSM 900 / 1800 myX-3 & myX-5 Document title: Site Technical Document for myX-3 & myX-5 Reference : Date : December 2002 Please fill in the following table : Excellent Good Fairly good Passable Easy to find the required information...

  • Page 11: Chapter 2 - Description - Operation

    Technical Site Documentation - GSM 900 / 1800 myX-3 & myX-5 CHAPTER 2 - DESCRIPTION - OPERATION REMINDERS ABOUT THE GENERAL CHARACTERISTICS OF GSM, (900 et 1800) AND PCS (GSM 1900) NETWORKS Table 1 below gives the characteristics of the radio interface for the GSM 900, GSM 1800 and GSM 1900...
  • Page 12 Technical Site Documentation - GSM 900 / 1800 myX-3 & myX-5 Table 3 shows power classes : Class 1 Class 2 Class 3 Class 4 Class 5 43 dBm 39 dBm 37 dBm 33 dBm 29 dBm 1800 30 dBm...
  • Page 13 Technical Site Documentation - GSM 900 / 1800 myX-3 & myX-5 REMINDERS ABOUT THE CHARACTERISTICS AND OPTIONS OF myX-3 & myX-5 MOBILES GENERAL CHARACTERISTICS myX-3 myX-3d myX-5 myX-5d Weight (in g) : Dimensions (in mm) : 106*46*20 105*46*20 Volume (cm3)
  • Page 14 Technical Site Documentation - GSM 900 / 1800 myX-3 & myX-5 MULTIMEDIA myX-3 myX-3d myX-5 MyX-5d Picture formats bmp, jpeg, png, gif Audio formats iMelody1.2, Midi, Wave Music file reproduction No possibility to forward a polyphonic tone Integrated still picture camera...

  • Page 15: Smk Connector

    Technical Site Documentation - GSM 900 / 1800 myX-3 & myX-5 SMK CONNECTOR 2.3.1 Connector description This connector is located at the bottom of the transmission module and enable the connection to various accessories. It comprises power supply pins and signals.
  • Page 16 Technical Site Documentation - GSM 900 / 1800 myX-3 & myX-5 (RXD2) RXDG SERIAL DATA TO BE TRANSMITTED. LOGICAL INPUT SERIAL DATA RECEIVED. TXDG LOGICAL OUTPUT Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002...
  • Page 17 Technical Site Documentation - GSM 900 / 1800 myX-3 & myX-5 SYMBOL SIGNAL FUNCTION NATURE CONNECTOR E/S, Al; Ana DIN32 RESET LOGICAL INPUT ITDATA Interruption signal keep SAGEM LOGICAL INPUT accessories. ZERO VOLT. SIGNAL GROUND BFRXP ANALOG OUTPUT Audio frequency signal received (φ 0).

  • Page 18: Identification

    Technical Site Documentation - GSM 900 / 1800 myX-3 & myX-5 IDENTIFICATION All phones are identified with an identification label sticked on the antenna. 2.4.1 Illustration 2.4.2 Description a : IMEI (bar code), b : IMEI (15 characters) c : Reference of product / aesthetic used .

  • Page 19: Phone Block Diagram

    EN 60950 , 73/23/CEE EQUIPEMENTS The description and operation of SAGEM myX-3 & myX-5 are given in the "User’s handbook" supplied with the handset. This chapter only describes equipment that operates with the myX-3 & myX-5 handset . Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002...

  • Page 20: Battery Packs

    Technical Site Documentation - GSM 900 / 1800 myX-3 & myX-5 2.6.1 Battery packs Over view 2.6.1.1 Characteristics Type Technology Weight Voltage capacity L720 Li-Ion 21 g 3,6 V / 720 mA/H 2.6.1.2 Description Li-ion type batteries are used. They are rechargeable using:...

  • Page 21: Mains Modules

    Site Technical Documentation - GSM 900/1800 - Serie 3000 2.6.1.3 Charging time The following table shows typical charging times for different batteries. Battery 500 mA travel AC* and K** "Simple" unregulated chargers chargers chargers 230 V Nom. (110 V Nom.) 94 V à...
  • Page 22 Site Technical Documentation - GSM 900/1800 - Serie 3000 TRAVEL 500 mA. AUS 110/230 V 2.6.2.3 Mains modules Reference Weight (g) Vol (cm Primary voltage SIMPLE UNREGULATED MAINS POWER SUPPLY MODULES 1.5 V. 300 mA. EC MAINS MODULE 230 V UK MAINS MODULE 230 V US MAINS MODULE...

  • Page 23: Chapter 3 - Symptoms

    The conclusion of each troubleshooting procedure is : • Return to SAGEM =The Return to the SAGEM centre can concern either the card, or the radiotelephone according to instructions given to the Centres of repair. •...

  • Page 24: Short Loop Process

    VERSION : 1.0 1. Initialization From the communication by Sagem and the reception of the concerned products by the short lopp process, the Repair Centre shall comply with the above procedure. The application of the Short loop process will end when received the authorization of repairing given by Sagem.
  • Page 25 Sagem. - The Out of warranty handsets and accessories (oxidation, shocks, …) will be repaired by the Repair Centre after acceptation by the customer of an estimate according to the Sagem out of warranty reapir prices communicated.
  • Page 26 Accessories + model (ex : myX-6) for the accessories received in the Repair Centre without the handsets. 7. Sagem Montauban Sagem Montauban will ship back to the Repair Centre the same quantity of handsets and accessories as the quantity received. Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 200229/03/01...
  • Page 27 Site Technical Documentation - GSM 900/1800 - Serie 3000 Appendix ADDITIONAL INFORMATION ABOUT THE NO FAULT FOUND In any case: Ask to the end-user the frequency of the defect and the circumstances of its apparition (during an incoming or out-going call, while playing, while downloading, etc.). Try to answer the questions: Where? When? How? •...

  • Page 28: List Of Reported Defects

    Site Technical Documentation - GSM 900/1800 - Serie 3000 LIST OF REPORTED DEFECTS The following is a list of defects that may be reported : Code Indicated fault Procedure Display malfunction Symp Sheet 04 No power up Proc Sheet 1 11 or 3 01 No display up Symp Sheet 04 Freezes up...
  • Page 29 Site Technical Documentation - GSM 900/1800 - Serie 3000 Unknown battery Test Sheet 03 Code Indicated fault Procedure Defective loudspeaker (hails) Symp Sheet 08 Loudspeaker voice distortion Symp Sheet 08 Defective microphone Symp Sheet 08 Microphone voice distortion Symp Sheet 08 Vibrating device malfunction Symp Sheet 07 Defective audio connector...

  • Page 30: Error Messages During Start Up

    Site Technical Documentation - GSM 900/1800 - Serie 3000 ERROR MESSAGES DURING START UP Message Meaning Procedure WARNING UNTUNED Invalid EEPROM field (SAGEM) SAGEM factory return RADIO PB IMEI Consistency problem at IMEI level SAGEM factory return SIM MISSING SIM card missing or badly inserted...
  • Page 31 Site Technical Documentation - GSM 900/1800 - Serie 3000 "PIN ERROR" " PIN input problems " "PIN2 BLOCKED" Following input errors "PUK ERROR" Following input errors Message Meaning "PUK2 BLOCKED" Following input errors "CODE ERROR" The phone code input for locking the mobile is incorrect "NOT AVAIL."...

  • Page 32: List Of Observed Defects

    A SAGEM code is assigned to each confirmed defect. This code should be entered on Proc Sheet 3 SAGEM Factory Return, if the phone to be repaired is returned to SAGEM (see chapter 5). Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 200229/03/01...

  • Page 33: Symptom Sheet

    Site Technical Documentation - GSM 900/1800 - Serie 3000 SYMPTOM SHEETS Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 200229/03/01 Page 3-27...
  • Page 34 ENDURANCE, BATTERY, CHARGER PROBLEM Symp Sheet 01 myX-3 & myX-5 Test the charger Test Sheet 02 Replace the Standard charger Test consumption Test Sheet 04 Hard. failure level 3 Proc Sheet 3 01 Test the battery Test Sheet 03 Replace the battery Proc Sheet 0 02 Ref.
  • Page 35 COMMUNICATION PROBLEM Symp Sheet 02 myX-3 & myX-5 Do the Wavetek test Fiche Test 06 Radio problem ? Return to SAGEM Proc sheet 1 11 ou Proc 3 01 Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 200229/03/01...
  • Page 36 NO FAULT GIVEN Symp Sheet 03 (Expertise of the phone) myX-3 & myX-5 Update with OMM Test Sheet 01 Charger Test Test Sheet 02 Fault found ? Battery test Test sheet 03 Fault found ? Consumption Test Test Sheet 04...
  • Page 37 DISPLAY PROBLEM Symp Sheet 04 myX-3 & myX-5 Test the display with the "Hotline" menu Black/ color screen Test Sheet 05 Ok ? Replace the display Proc Sheet 1 06 Test the display with the "Hotline" menu Test Sheet 05...
  • Page 38 KEYPAD PROBLEM Symp Sheet 05 myX-3 & myX-5 Set the “Keypad beep” function Test the keypad by listening to the key beep Replace a new metal dome Proc Sheet Repeat the keypad test Return to SAGEM Proc Sheet 1 11 or Proc 3 01 Ref.
  • Page 39 RING TONES PROBLEM Symp Sheet 06 myX-3 & myX-5 Select “Vibrate only” function” SOUNDS/VIBRATE" menu Check ring tones with incoming call Ok ? Replace loudspeaker CHAPTER 1 - Ok ? Return to SAGEM Proc Sheet 1 11 or Proc 3 01 Ref.
  • Page 40 VIBRATING DEVICE Symp Sheet 07 myX-3 & myX-5 Test the vibrating device with the hotline menu Perform radio test Test Sheet 05 Test Sheet 06 Ok ? Audio Problem ? audio ? Replace the vibrating device Proc Sheet 1 10...

  • Page 41: Chapter 4 - Tests And Checks

    They are broken down into modules and are sorted by types of confirmed faults. The user must be equipped with special test tools in order to carry out the tests. TEST TOOLS The references of SAGEM tools, listed hereafter, are given in Appendix 1 : Composition table. The following test tools are necessary : −...
  • Page 42 Site Technical Documentation – GSM 900 / 1800 myX-3 & myX-5 Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002 Page 4-36...

  • Page 43: Installing On A Workstation

    Site Technical Documentation – GSM 900 / 1800 myX-3 & myX-5 INSTALLING ON A WORKSTATION 4.3.1 Minimum required configuration The minimum configuration of the workstation is : − Processor 1Ghz, − 128 Mbytes of RAM, − Windows (S.R2), Windows NT (SP 4), Windows 2000, Windows XP, −...

  • Page 44: Test Sheet

    Site Technical Documentation – GSM 900 / 1800 myX-3 & myX-5 TEST SHEET Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002 Page 4-38...
  • Page 45 TEST AND CHECK BY OMM Test Sheet 01 myX-3 & myX-5 To run the functions described below, run the OMM application from the desktop icon. Notice: The active connection with OMM ( via the serial port ), validate in itself the data functionality of the handset.
  • Page 46 TEST AND CHECK BY OMM Test Sheet 01 myX-3 & myX-5 LABEL : Print identification labels 1. Click on the on LABEL popup menu and then PRINT LABEL . 2. Follow the procedures on the screen AUDIO : Audio parameters setting...
  • Page 47 TEST AND CHECK BY OMM Test Sheet 01 myX-3 & myX-5 SWAP : Electronic board Configuration plug the connector of downloading kit into the defective board perform the step 1 by placing a keypad on the turn on the defective board and by...
  • Page 48 TEST AND CHECK BY OMM Test Sheet 01 myX-3 & myX-5 Step 1 OMM Front page Click on the « SWAP » menu. The following screen appears : Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002...
  • Page 49 TEST AND CHECK BY OMM Test Sheet 01 myX-3 & myX-5 Step 2 Please click on « SWAP » button to launch the swap board sequence Step 3a The following screen appears : the mobile is recognized. Please follow the instructions pop up Ref.
  • Page 50 TEST AND CHECK BY OMM Test Sheet 01 myX-3 & myX-5 Step 3b The mobile is not recognized, Select « IGNORE »and please follow the instruction according to the functional state of the mobile Step 3c The following screen appears, you must fill in the empty blanks requested according to the information written on the production label Ref.
  • Page 51 TEST AND CHECK BY OMM Test Sheet 01 myX-3 & myX-5 Step 4 After clicking on “OK”, OMM prints the label which will be used to close the ESD bag of the defective board. Step 5 Then, plug the functional mobile and click on “SWAP”...
  • Page 52 TEST AND CHECK BY OMM Test Sheet 01 myX-3 & myX-5 Step 6 When the downloading is over, automatically the checking step starts. Step 7 OMM opens the following screen to print the new label : please dial the “MAKING DATE” written on the label of the defective mobile.
  • Page 53 TEST AND CHECK BY OMM Test Sheet 01 myX-3 & myX-5 RESULTS When old mobile recognized, the audio parameters from the defective mobile have been sent to the functional mobile. When old mobile is not recognized, the DEFAULTS audio parameters are sent to the functional mobile.
  • Page 54 CHARGER TEST Test Sheet 02 myX-3 & myX-5 Test description This test checks the various battery chargers. Required tools − a voltmeter (minimum impedance 20 kΩ per Volt in DC), − two sockets for banana connectors for connection to the voltmeter, −...
  • Page 55 Test description This test allows to test the various batteries. Required tools − CADEX C7000 / C7200 / ASTRATEK − myX-3 & myX-5 adapters, − myX-3 Ammeter interface − myX-5 Ammeter interface − a voltmeter (minimum impedance 20 kΩ per Volt in DC).
  • Page 56 CONSUMPTION TEST Test Sheet 04 myX-3 & myX-5 Test description This test tests the battery consumption. Required tools − myX-3 Ammeter interface − myX-5 Ammeter interface − An Ammeter. Test procedure Measurement when switched off 17. Insert the mobile (switched off) onto the tool (customer phone and battery).
  • Page 57 "HOTLINE" MENU Test Sheet 05 myX-3 & myX-5 Access to the "HOTLINE" menu Access to the "HOTLINE" menu is possible with a powered up mobile. The "HOTLINE" menu is accessed by pressing on the ∇ ∇ ∇ ∇ key and then the * key.
  • Page 58 "HOTLINE" MENU Test Sheet 05 myX-3 & myX-5 Description of the myX-5 "HOTLINE" menu APPLICATION gives the value of the battery voltage. • BATTERY : • reads the installed software version and the IMEI code. VERSION : PROM : Not used accesses the "SIM LOCK"...
  • Page 59 Test procedure 0-15V /4A 25. Position the myX-3 or myX-5 module on the radio interface (1) (provided with a SIM test card) 26. Press and lock the button (2) , press the start key 27. Switch the Wavetek on and press on "AUTOTEST".

  • Page 60: Chapter 5 - Maintenance Procedures

    Site Technical Documentation – GSM 900 / 1800 myX-3 & myX-5 CHAPTER 5 - MAINTENANCE PROCEDURES TECHNICAL WORK LEVELS There are four technical work levels: Level 0, Level 1, Level 2, Level 3. Each level represents a maintenance degree that depends on which elements are to be removed.

  • Page 61: Level 0 Maintenance

    Site Technical Documentation – GSM 900 / 1800 myX-3 & myX-5 LEVEL 0 MAINTENANCE Page 5-3...
  • Page 62 REMOVING / REPLACING BACK COVER Proc Sheet 0 01 myX-3 & myX-5 Tools : Not applicable. Preliminary operation Turn the handset upside down Removal procedure : Unlock the back cover (1) , by pushing the lock button (2) upwards. Remove rear cover (1) by lifting bottom end first Placement procedure : 1.
  • Page 63 REMOVING / REPLACING THE BACK COVER Proc sheet 0 01 myX-3 & myX-5 Page 5-4 Ref. SCT U38 SSC DTS 009 – Index B -...
  • Page 64 REMOVING / REPLACING THE BATTERY Proc Sheet 0 02 myX-3 & myX-5 4.10 Tools : 4.11 - Not applicable 4.12 Preliminary operation : 4.13 - Switch off the mobile phone 4.14 Removal procedure : 1. Remove the back cover ( Proc sheet 0 01).
  • Page 65 REMOVING / REPLACING THE BATTERY Proc Sheet 0 02 myX-3 & myX-5 Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002 Page 5-7...
  • Page 66 REMOVING / REPLACING THE FRONT COVER Proc Sheet 0 03 myX-3 & myX-5 4.16 Tools : - Not applicable 4.17 Preliminary operation : Remove the back cover ( Proc sheet 0 01). 4.18 Removal procedure : 30. Separate the two front cover (2) fixing stop pins (3) to release the electronic module (1).
  • Page 67 REMOVING / REPLACING THE FRONT COVER Proc sheet 0 03 myX-3 & myX-5 Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002 Page 5-9...
  • Page 68 REMOVING / REPLACING THE ELASTOMER Proc Sheet 0 04 KEYPAD myX-3 & myX-5 4.21 Tools : - Not applicable 4.22 Preliminary operation 1. Remove the back cover ( Proc sheet 0 01). 2. Remove the front cover ( Proc sheet 0 03).
  • Page 69 REMOVING / REPLACING THE ELASTOMER Proc Sheet 0 04 KEYPAD myX-3 & myX-5 Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002 Page 5-11...
  • Page 70 REMOVING / REPLACING THE KNOB Proc Sheet 0 05 LOCK AND THE LOCKER myX-3 & myX-5 4.26 Tools : - Not applicable 4.27 Preliminary operation 33. Remove the back cover ( Proc sheet 0 01). 4.28 Removal procedure : 1. Push the knob lock (1) upward .
  • Page 71 REMOVING / REPLACING THE KNOB Proc Sheet 0 05 LOCK AND THE LOCKER myX-3 & myX-5 KNOB LOCK LOCKER Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002 Page 5-13...
  • Page 72 REMOVING / REPLACING THE KNOB Proc Sheet 0 05 LOCK AND THE LOCKER myX-3 & myX-5 Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002 Page 5-14...

  • Page 73: Level 1 Maintenance

    Site Technical Documentation – GSM 900 / 1800 myX-3 & myX-5 LEVEL 1 MAINTENANCE Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002 Page 5-15...
  • Page 74 (Proc sheet 0 02). 3. Replace the back cover (Proc sheet 0 01). 4. Set the display parameters with OMM software (only for myX-5) (Test Sheet 01) 5. Carry out the radio test (Test Sheet 06). Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002...
  • Page 75 REMOVING / REPLACING THE DISPLAY Proc Sheet 1 02 myX-3 & myX-5 Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002 Page 5-17...
  • Page 76 REMOVING / REPLACING THE LIGHT GUIDE Proc Sheet 1 03 KEYPAD myX-3 & myX-5 4.36 Tools : - A 0.6mm torx screwdriver 4.37 Preliminary operation 1. Remove the back cover ( Proc sheet 0 01). 2. Remove the battery ( Proc sheet 0 02).
  • Page 77 REMOVING / REPLACING THE LIGHT GUIDE Proc Sheet 1 03 KEYPAD myX-3 & myX-5 Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002 Page 5-19...
  • Page 78 REMOVING / REPLACING THE ELECTRONIC Proc Sheet 1 04 BOARD myX-3 & myX-5 4.41 Tools : - A 0.6mm torx screwdriver 4.42 Preliminary operation 1. Remove the back cover ( Proc sheet 0 01). 2. Remove the battery ( Proc sheet 0 02).
  • Page 79 REMOVING / REPLACING THE ELECTRONIC Proc Sheet 1 04 BOARD myX-3 & myX-5 Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002 Page 5-21...
  • Page 80 REMOVING / REPLACING THE METAL DOME Proc Sheet 1 05 myX-3 & myX-5 4.46 Tools : - A 0.6mm torx screwdriver - Gloves - Metal dome Jig Tweezers 4.47 Preliminary operation This procedure must be performed by a technician with gloves.
  • Page 81 REMOVING / REPLACING THE METAL DOME Proc Sheet 1 05 myX-3 & myX-5 Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002 Page 5-23...
  • Page 82 REMOVING / REPLACING THE SIM LOCKER Proc Sheet 1 06 myX-3 & myX-5 4.51 Tools : - A 0.6mm torx screwdriver 4.52 Preliminary operation : 1. Remove the back cover ( Proc sheet 0 01). 2. Remove the battery ( Proc sheet 0 02).
  • Page 83 REMOVING / REPLACING THE SIM LOCKER Proc Sheet 1 06 myX-3 & myX-5 Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002 Page 5-25...
  • Page 84 REMOVING / REPLACING THE BATTERY Proc Sheet 1 07 CONNECTOR myX-3 & myX-5 4.56 Tools : - A 0.6mm torx screwdriver - Tweezers 4.57 Preliminary operation 1. Remove the back cover ( Proc sheet 0 01). 2. Remove the battery ( Proc sheet 0 02).
  • Page 85 REMOVING / REPLACING THE BATTERY Proc Sheet 1 07 CONNECTOR myX-3 & myX-5 Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002 Page 5-27...
  • Page 86 REMOVING / REPLACING THE MICROPHONE Proc Sheet 1 08 myX-3 & myX-5 4.61 Tools : - A 0.6mm torx screwdriver - Tweezers 4.62 Preliminary operation 1. Remove the back cover ( Proc sheet 0 01). 2. Remove the battery ( Proc sheet 0 02).
  • Page 87 REMOVING / REPLACING THE MICROPHONE Fiche Proc 1 08 myX-3 & myX-5 Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002 Page 5-29...
  • Page 88 REMOVING / REPLACING THE LOUDSPEAKER Proc Sheet 1 09 myX-3 & myX-5 4.66 Tools : - A 0.6mm torx screwdriver - Tweezers 4.67 Preliminary operation 1. Remove the back cover ( Proc sheet 0 01). 2. Remove the battery ( Proc sheet 0 02).
  • Page 89 REMOVING / REPLACING THE LOUDSPEAKER Proc Sheet 1 09 myX-3 & myX-5 Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002 Page 5-31...
  • Page 90 REMOVING / REPLACING THE LOUDSPEAKER Proc Sheet 1 09 myX-3 & myX-5 Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002 Page 5-32...
  • Page 91 REMOVING / REPLACING THE VIBRATING Proc Sheet 1 10 DEVICE myX-3 & myX-5 4.71 Tools : - A 0.6mm torx screwdriver - Tweezers 4.72 Preliminary operation : 1. Remove the back cover ( Proc sheet 0 01). 2. Remove the battery ( Proc sheet 0 02).
  • Page 92 REMOVING / REPLACING THE VIBRATING Proc Sheet 1 10 DEVICE myX-3 & myX-5 Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002 Page 5-34...
  • Page 93 Note : The defective board must never be mixed with the complete mobiles 4.78 Placement procedure : 1. Take a board in the stock of swap boards from the same Sagem reference. 4.79 Further operations : 1. Place the new electronic board on the assembly plate.
  • Page 94 & myX-5 Example of electronic boards packaging : Electronic board ESD shielding bag Humidity absorber Boards packaging SAGEM -> ARC Boards packaging ARC -> SAGEM ESD shielding bag closed by ESD shielding bag closed by the IMEI label the product label Ref.
  • Page 95 ELECTRONIC BOARD EXCHANGE Proc sheet 1 11 myX-3 & myX-5 SAGEM electrostatic shielding box Reference 20 boards: 27441180-4 Reference 100 boards: 27 511110-6 Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002 Page 5-37...
  • Page 96 ELECTRONIC BOARD EXCHANGE Proc sheet 1 11 myX-3 & myX-5 Electronic board exchange process Mobile phone with N3 defect Detection of N3 defect : See the Technical documentation Remove the electronic board from the defective mobile Proc 1.10 Microphone and loudspeaker replacement Proc 1.04/1.05...
  • Page 97 ECHANGE CARTE ELECTRONIQUE Fiche Proc 2 01 Tous types Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002 Page 5-39...

  • Page 98: Level 3 Maintenance

    Site Technical Documentation – GSM 900 / 1800 myX-3 & myX-5 LEVEL 3 MAINTENANCE Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002 Page 5-40...
  • Page 99 Site Technical Documentation – GSM 900 / 1800 myX-3 & myX-5 IMPORTANT Mobile packaging sent to SAGEM S.A. : Follow the Proc sheet 1.11 Packaging for swap or mobile components storage : The swap and the mobile components must be stored with a particular care especially for the most sensible component (Display , loudspeaker etc…).
  • Page 100 RETURN TO SAGEM FACTORY Proc Sheet 3 01 Informations CRA/CRA information : Garantie/Warranty : Nom/Name : Garantie standard/Standard warranty : Rue /Street : Déjà réparé/préviously repaired : Ville / City : Hors garantie/Out of warranty : Code postal /Poscode : Garantie expirée /Expired warranty :...
  • Page 101 Technical Site Documentation - GSM 900 / 1800 myX-3 & myX-5 Ville / City : Code postal /Poscode : Pays/Country Telephone /Phone : Nom du produit/product : N° Série/Sérial n° : Date d' achat/Date of purchase N° IMEI : Garantie/Warranty :...

  • Page 102: Chapter 6 - Accessories

    Technical Site Documentation - GSM 900 / 1800 myX-3 & myX-5 CHAPTER 6 - ACCESSORIES 4.80 12 V / 24 V CHARGERS 4.80.1 Description This charger is for use in a car (or truck) only. The adapter is fitted with a cigar lighter type connector.

  • Page 103: Desktop Chargers And Cradles

    Technical Site Documentation - GSM 900 / 1800 myX-3 & myX-5 4.81 DESKTOP CHARGERS AND CRADLES 4.81.1 Description This charger could charge a mobile, while acting as holder the handset. 4.81.2 Characteristics Item Designation Nature SIMPLE DESKTOP Simple support recess CRADLE Ref.

  • Page 104: Car Cradle

    Technical Site Documentation - GSM 900 / 1800 myX-3 & myX-5 4.82 CAR CRADLE 4.82.1 Description Car cradle compatible with AC1 or antenna adapter. 4.82.2 Characteristics Item Packaging Comments CAR CRADLE BLISTER Mechanical craddle KIT mechanical Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002...

  • Page 105: Full Duplex Car Handsfree Kit

    Site Technical Documentation – GSM 900 / 1800 myX-3 & myX-5 4.83 FULL DUPLEX CAR HANDSFREE KIT 6.4.1. Description Rapido Kit : "compact" kit on cigar lighter, Kit K3 : "confort" kit for integration in car with phone equipment. 6.4.2.
  • Page 106 Site Technical Documentation – GSM 900 / 1800 myX-3 & myX-5 Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002 Page 8-3...
  • Page 107 Site Technical Documentation – GSM 900 / 1800 myX-3 & myX-5 Item Packaging Comments KIT K3 No antenna. Requires car installation 900/1800 MHz dual band 1 : Loudspeaker. 2 : Cradle. 3 : Microphone. 4 : Connecting case. 5 : Power supply cable.

  • Page 108: Pedestrian Handsfree Kit

    Site Technical Documentation – GSM 900 / 1800 myX-3 & myX-5 PEDESTRIAN HANDSFREE KIT 4.5.1 Description Ear support with microphone on the cable for handsfree conversation. 4.5.2 Characteristics Item Dimensions Loudspeaker Microphone impedance 150 Ω 2,2 kΩ PEDESTRIAN Length: 1.25 m...

  • Page 109: Data Cables

    Site Technical Documentation – GSM 900 / 1800 myX-3 & myX-5 DATA CABLES 4.6.1 Description Data cables are used for transferring data through standard equipment. 4.6.2 Characteristics Item Packaging Target mobile Mobile link to Signals Standard V28 Range 3V<Us<-3V 900/3000/myX-...

  • Page 110: Chapter 7 - Technical Information Bulletin

    Site Technical Documentation – GSM 900 / 1800 myX-3 & myX-5 CHAPTER 7 - TECHNICAL INFORMATION BULLETIN PURPOSE The purpose of the Technical Information Bulletin (TIB) is to complete the maintenance operations described in this document. They give to the repair centers the complementary technical informations and the corrective procedures to be applied to maintain the product following it' s evolution.

  • Page 111: Chapter 8 - Illustrated Parts Catalog

    Site Technical Documentation – GSM 900 / 1800 myX-3 & myX-5 CHAPTER 5 - ILLUSTRATED PART CATALOG myX-3 spare parts ASSEMBLY DESIGNATION Glass Front cover Elastomer keyboard Rear cover Assembly plate Metal dome Light guide keypad RLX 1,8-6 screw Black & white display...
  • Page 112 Site Technical Documentation – GSM 900 / 1800 myX-3 & myX-5 Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002 Page 8-3...

  • Page 113: Myx-5 Spare Parts

    Site Technical Documentation – GSM 900 / 1800 myX-3 & myX-5 myX-5 spare parts ASSEMBLY DESIGNATION Glass Front cover Elastomer keyboard Rear cover Assembly plate Metal dome Light guide keypad RLX 1,8-6 screw Colour display Display support Display clamp Plate...
  • Page 114 Site Technical Documentation – GSM 900 / 1800 myX-3 & myX-5 Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002 Page 8-3...
  • Page 115 Site Technical Documentation – GSM 900 / 1800 myX-3 & myX-5 Ref. SCT U38 SSC DTS 009 – Index B - December 12 , 2002 Page 8-3...
  • Page 116 Site Technical Documentation – GSM 900 / 1800 myX-3 & myX-5 APPENDIX 1 - COMPOSITION TABLE PURPOSE This chapter contains the SAGEM codes of articles mentioned throughout the Site Technical Documentation. LIST OF ARTICLES BATTERIES Designation Référence Flat Li-Ion 720 mAh 18 778 323-2 4.5 V 400 mA MAINS MODULES...
  • Page 117 Site Technical Documentation – GSM 900 / 1800 myX-3 & myX-5 12 V / 24 V CHARGERS Designation Reference Cigar-lighter charger AC1 23 810 045 - 9 DESKTOP CHARGERS Designation Reference Desktop charger 23 812 376 - 7 FULL DUPLEX CAR HANDSFREE KIT...
