User Interface
5.1.2 Setting LCP Display Values
The display area is activated when the frequency converter
receives power from mains voltage, a DC bus terminal, or
an external 24 V DC supply.
The information displayed on the LCP can be customised
for user application.
•
Each display readout has a parameter associated
with it.
•
Options are selected in the quick menu Q3-13
Display Settings.
•
Display 2 has an alternate larger display option.
•
The frequency converter status at the bottom line
of the display is generated automatically and is
not selectable.
Status
0.0%
1.1
1.2
Off Remote Stop
2
3
Display
Parameter number
1.1
0-20
1.2
0-21
1.3
0-22
2
0-23
3
0-24
Illustration 5.2 Display Readouts
MG16J202
Operating Instructions
1 (1)
0.00 A
0.00 kw
0.0Hz
2605kWh
1.3
Default setting
Reference %
Motor current
Power [kW]
Frequency
kWh counter
Danfoss A/S © Rev. 05/2014 All rights reserved.
5.1.3 Display Menu Keys
Menu keys are used for menu access for parameter set-up,
toggling through status display modes during normal
operation, and viewing fault log data.
Quick
Status
Menu
Illustration 5.3 Menu Keys
Key
Function
Status
Shows operational information.
•
In Auto mode, press to toggle between
status readout displays.
•
Press repeatedly to scroll through each
status display.
•
Press [Status] plus [
display brightness.
•
The symbol in the upper right corner of the
display shows the direction of motor
rotation and which set-up is active. This is
not programmable.
Quick Menu
Allows access to programming parameters for
initial set-up instructions and many detailed
application instructions.
•
Press to access Q2 Quick Set-up for
sequenced instructions to program the basic
frequency controller set-up.
•
Follow the sequence of parameters as
presented for the function set-up.
Main Menu
Allows access to all programming parameters.
•
Press twice to access top-level index.
•
Press once to return to the last location
accessed.
•
Press to enter a parameter number for
direct access to that parameter.
Alarm Log
Displays a list of current warnings, the last 10
alarms, and the maintenance log.
•
For details about the frequency converter
before it entered the alarm mode, select the
alarm number using the navigation keys
and press [OK].
Table 5.6 Function Description Menu Keys
Main
Alarm
Menu
Log
▲
▼
] or [
] to adjust the
65
5
5
