2N EasyGate Pro
GSM gateway
User Manual
Version:
1.0
www.2n.cz

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EasyGate Pro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for 2N EasyGate Pro

Summary of Contents for 2N EasyGate Pro

  • Page 1 ® 2N EasyGate Pro GSM gateway User Manual Version: www.2n.cz...
  • Page 2 2N TELEKOMUNIKACE a.s. administers the FAQ database to help you quickly find information and to answer your questions about 2N products and services. On www. faq.2n.cz you can find information regarding products adjustment and instructions for optimum use and procedures „What to do if...".

  • Page 3: Table Of Contents

    2.1 Description 2.2 Before You Start 2.3 Mounting 2.4 Telephone Line Connection 2.5 SMS Sending Input Connection 3. 2N® EasyGate PRO Configuration 3.1 2N® EasyGate PRO Configuration 3.2 Table of Parameters 4. Function and Use 4.1 Voice Function 4.2 FAX and Data Function 4.3 SMS Sending Input...

  • Page 4: Product Overview

    This chapter also includes safety instructions. Here is what you can find in this section: 1.1 Product Description 1.2 Changes 1.3 Terms and Symbols Used 2N TELEKOMUNIKACE a.s., www.2n.cz 4/70...

  • Page 5: Product Description

    Radiation hazard minimization you are not exposed to a direct effect of the antenna RF electromagnetic field while telephoning as opposed to mobile telephones. Full GSM coverage EasyGate is available in version quadband (850, 900, 1800, 1900MHz). 2N TELEKOMUNIKACE a.s., www.2n.cz 5/70...

  • Page 6: Safety Precautions

    EasyGate to another power supply, make sure that the voltage value is in the acceptable range. When your EasyGate comes to the end of its operational life, dispose of it in accordance with applicable regulations. 2N TELEKOMUNIKACE a.s., www.2n.cz 6/70...

  • Page 7: Changes

    EasyGate II product line: 501323, 501333, 501343 and 501353. 1.01 Name changed to EasyGate PRO, minor changes Cautions The manufacturer continuously meets customer requirements by improving the firmware. For the latest EasyGate processor firmware, programming tool and User Manual see www.2n.cz...

  • Page 8: Terms And Symbols Used

    Useful information for quick and efficient functionality. Note Routines or advice for efficient use of the device. Future functions Grey marked text in this document specifies functions of EasyGate , which will be supported in the future. 2N TELEKOMUNIKACE a.s., www.2n.cz 8/70...

  • Page 9: Description And Installation

    This section describes the EasyGate PRO product and its installation. Here is what you can find in this section: 2.1 Description 2.2 Before You Start 2.3 Mounting 2.4 Telephone Line Connection 2.5 SMS Sending Input Connection 2N TELEKOMUNIKACE a.s., www.2n.cz 9/70...

  • Page 10: Description

    EasyGate consites of GSM gateway in white plastic cover, removable antenna and cables for connecting to phone set and PC. ® EasyGate 's status is indicated by LED diodes on its front side. All possible states are described in the following figure. 2N TELEKOMUNIKACE a.s., www.2n.cz 10/70...
  • Page 11 Dialing end signaling Dialing reception has been terminated. Connection is being established. PIN tone Enter the PIN code. This tone is transmitted upon power up if the PIN has to be entered manually. PUK tone 2N TELEKOMUNIKACE a.s., www.2n.cz 11/70...
  • Page 12 Confirms that the service password or parameter number entered is correct and has been accepted. Refusal Incorrect parameter number; Incorrect parameter value Transmitted when a parameter is cancelled with a Saving Parameter value entered is correct and has been saved. 2N TELEKOMUNIKACE a.s., www.2n.cz 12/70...

  • Page 13: Before You Start

    GSM signal is good or when the antenna with cable is used. Install EasyGate with respect to the GSM signal strength – check the signal strength using the PCManager or LED indicator. 2N TELEKOMUNIKACE a.s., www.2n.cz 13/70...
  • Page 14 EasyGate is not designed for environments with high vibrations such as means of transport, machine rooms, etc . Caution Check that you have everything needed for EasyGate start-up (SIM card, analogue phone set or FXO port of PBX, eventually PC etc.) 2N TELEKOMUNIKACE a.s., www.2n.cz 14/70...

  • Page 15: Mounting

    EasyGate version. Operator services and SIM card services, such as preferred networks, SMS service centre, PIN protection etc. must be set in your mobile phone before inserting your SIM card into EasyGate. 2N TELEKOMUNIKACE a.s., www.2n.cz 15/70...

  • Page 16: Power Supply Connection

    The battery should never be placed in municipal waste. Please check local regulations for disposal of batteries. 2N TELEKOMUNIKACE a.s., www.2n.cz 16/70...

  • Page 17: Telephone Line Connection

    EasyGate. Optionally you can connect analogue fax (special model of EasyGate). EasyGate is equipped with the FSK-based CLIP and so it is advantageous to connect a terminal that is able to display the CLIP. 2N TELEKOMUNIKACE a.s., www.2n.cz 17/70...

  • Page 18: Sms Sending Input Connection

    A transistor switch or logic signal can be used too. The pin near the telephone line connector is connected to GND of the device the second one is active. Please, respect the loop current polarity. The input is over-voltage protected (up to +12V DC). 2N TELEKOMUNIKACE a.s., www.2n.cz 18/70...

  • Page 19: N® Easygate Pro Configuration

    3. 2N® EasyGate PRO Configuration ® This section describes configuration of the product EasyGate PRO Here is what you can find in this section: 3.1 2N® EasyGate PRO Configuration 3.2 Table of Parameters 2N TELEKOMUNIKACE a.s., www.2n.cz 19/70...

  • Page 20: Easygate Parameter Programming

    3.1 2N® EasyGate PRO Configuration PC Connection An USB cable is added to the package. Use it to interconnection PC and EasyGate. Caution If is used another USB cable make sure that a longer cable works properly to avoid errors at high transmission rates.

  • Page 21: Pc Based Programming

    For programming, connect EasyGate to a PC with a USB cable and make sure that the PCManager UNI is installed. Programming is intuitive and easy. All steps are accompanied with texts hints above all items you point at with the mouse. 2N TELEKOMUNIKACE a.s., www.2n.cz 21/70...
  • Page 22 Install PCManagerSmG from CD. Run EasyGate PCManager, select the language on the upper bar. In menu Program select Setup. Set the COM port – local and select COM port number according information from point 3. 2N TELEKOMUNIKACE a.s., www.2n.cz 22/70...

  • Page 23: Further Data Handling Options

    EasyGate before parameters programming and saving. If you only save data after PCManager UNI start, all parameters except the PIN and service password in the EasyGate memory will have default values. 2N TELEKOMUNIKACE a.s., www.2n.cz 23/70...

  • Page 24: Firmware Upgrade

    If there is more then one file in the PCManager directory, chose one of them. The upgrade takes place automatically. Do not switch your PC or EasyGate off during the process of upgrading! 2N TELEKOMUNIKACE a.s., www.2n.cz 24/70...
  • Page 25 EasyGate too but the PCManager requires confirmation to be on the safe side. Caution The manufacturer responds to clients' requirements with periodical firmware updating. The current EasyGate firmware, PCManager and User Manual are available on www.2n.cz 2N TELEKOMUNIKACE a.s., www.2n.cz 25/70...
  • Page 26 Telephone interface FXS parameters Dialing parameters Type of dialing (Function No.:100) Select the dialing type to be received by EasyGate on the FXS interface. 2N® EasyGate accepts only the selected type of dialing, ignoring the others. Setting options: DTMF (0) -EasyGate receives tone dialing only.
  • Page 27 Call end (1) - EasyGate sends tariff pulse when call ends. Call start (2)- EasyGate sends tariff pulse when call starts. Call start and end (3) - EasyGate sends tariff pulse when call starts and ends too. Default setting: None 2N TELEKOMUNIKACE a.s., www.2n.cz 27/70...

  • Page 28: Tone Settings

    Default setting: 425 Hz Dial tone - cadence (Function No.:122) Dial tone cadence setting. Setting options: Continuous ( 0) - EasyGate generate continuous dial tone Morse A (1) - EasyGate generate dial tone with 330/330/660/660 ms timing 2N TELEKOMUNIKACE a.s., www.2n.cz 28/70...
  • Page 29 Default setting: 425 Hz Ringback tone – frequency 2 [Hz] (Function No.:127) Setting of frequency 2 of ringback tone. Setting options: 1-3400 Hz Setting step: 1 Hz Default setting: 425 Hz Ringback tone - cadence (Function No.: 128) 2N TELEKOMUNIKACE a.s., www.2n.cz 29/70...
  • Page 30 Setting step: 1 Default setting: 3 = medium volume level Reception volume (Function No.:191) Volume setting for GSM reception with a 4 dB step. Setting options: 1-5 Setting step: 1 Default setting: 3 = medium volume level 2N TELEKOMUNIKACE a.s., www.2n.cz 30/70...
  • Page 31 If this parameter is filled, the + character in the international prefix of CLI is replaced by the defined string. The + character can neither be transmitted by the FSK protocol nor dialed by the DTMF from a terminal. Setting options: 0-4 characters (0-9,*,#) Default setting: blank 2N TELEKOMUNIKACE a.s., www.2n.cz 31/70...

  • Page 32: Fxs Routing Parameters

    Any table line that starts with the same prefix followed by one or more digits is considered an exception of the line with shorter prefix. Remember to complete the "Other numbers" line for a number whose prefix is not included in the table. 2N TELEKOMUNIKACE a.s., www.2n.cz 32/70...
  • Page 33 A prefix identifying the call type (GSM, trunk call, free call, etc.). "Other numbers" line used calls with prefixes that included table. Setting options:0-14 characters (0-9,*,#) Default setting: blank Call enable (Function No.: 391) This parameter allows/bars calls with prefixes included on the same line. Setting options: YES/NO 2N TELEKOMUNIKACE a.s., www.2n.cz 33/70...
  • Page 34 Pseudo tariff metering setting (tariff is based on call duration). The Extra tariff parameter defines transmitting of fixed quantity of tariff pulses after call start. This parameter sets minimal call cost. Setting options: 0-255 Setting step: 1 Default setting: 0 2N TELEKOMUNIKACE a.s., www.2n.cz 34/70...
  • Page 35 FXS line Off-Hook to DISA timeout [ms] (Function No.: 500) Timeout between FXS line Off-Hook and automatic dial in according to parameter "Dial in" in the table. Setting options: 100-25500 ms Setting step: 100 ms Default setting: 2000 ms 2N TELEKOMUNIKACE a.s., www.2n.cz 35/70...
  • Page 36 DATA calls are routed always to serial line. Setting options: -FXS line - Incoming DATA call is routed to modem on FXS line -COM - Incoming DATA call is routed to COM Default setting: FXS line 2N TELEKOMUNIKACE a.s., www.2n.cz 36/70...
  • Page 37 - It means inclusive of + and international prefix if they are included. If parameter "Substring" > 0, 2N® SmartGate UMTS searches filled prefix as substring of the received CLI, but max. to position given by "Substring"...

  • Page 38: Sms Sending Input Parameters

    Default setting: blank SMS text (Function No.:-) The SMS text to be sent to the preset telephone number. If the SMS text is blank, an empty SMS is sent. Setting options: 0-40 characters Default setting: blank 2N TELEKOMUNIKACE a.s., www.2n.cz 38/70...
  • Page 39 You can make EasyGate work even if it is registered to a foreign GSM network. Setting options: -Disable (0) - The GSM module logs out of a foreign network and attempts to register again in within 5 minutes. -Enable (1) - EasyGate works in any GSM network. 2N TELEKOMUNIKACE a.s., www.2n.cz 39/70...
  • Page 40 Code for credit checking (Function No.: 711) Credit in prepaid SIM cards is checked by network function, which displays text message on mobile phone display. Code of network function must be terminated with "#" symbol. 2N TELEKOMUNIKACE a.s., www.2n.cz 40/70...
  • Page 41 Telephone number for service SMS Telephone number for service SMS. The number is common for GGMC SMS, for "LOW CREDIT" SMS on prepaid SIM cards and for battery status SMS. To be set in part Service. 2N TELEKOMUNIKACE a.s., www.2n.cz 41/70...
  • Page 42 Setting options: 0-16 characters (0-9,*,#,+) Default setting: blank Time period for GGMC SMS [h] (Function No.: 970) Time interval for GGMC SMS sending. GGMC = GSM Gateway Monitoring Centre. The "0" setting means that the function is disabled. 2N TELEKOMUNIKACE a.s., www.2n.cz 42/70...
  • Page 43 PIN code). SMS input initialization (Function No.: -) Initialization of all parameters for SMS sending upon SMS input activation. Global initialization (Function No.: 999) Initialization of all EasyGate parameters including the PIN and service password. 2N TELEKOMUNIKACE a.s., www.2n.cz 43/70...

  • Page 44: Security Parameters

    Fill the service password for programming via a telephone line. Some parameters can be programmed by DTMF dialing and so the access to programming must be password-protected. Setting options:4-8 characters (0-9) Upon full initialization: 12345 2N TELEKOMUNIKACE a.s., www.2n.cz 44/70...

  • Page 45: Function And Use

    4. Function and Use ® This section describes the basic and extending functions of the product 2N EasyGate Here is what you can find in this section: 4.1 Voice Function 4.2 FAX and Data Function 4.3 SMS Sending Input 4.4 Data Connection Using USB Port 4.5 SIM Card PIN protection...

  • Page 46: Voice Function

    Hook off the phone to establish the call. The Line LED is permanently on during the call. Hang up to terminate the call. The Line LED goes off. If the called subscriber is the first to hang up, you can hear the busy tone and hang up. 2N TELEKOMUNIKACE a.s., www.2n.cz 46/70...

  • Page 47: Tariff Pulses 16 Or 12 Khz

    Wait for information tone. You may wait about 3 seconds. Hook on. Information tones: Confirmation - OK: Confirms that the service was configured correctly. Confirmation - bad: Service was not correctly configured Service isn't activated by your provider 2N TELEKOMUNIKACE a.s., www.2n.cz 47/70...

  • Page 48: Call Forwarding

    Call forwarding unconditional If activated, incoming calls will be always forwarded to the configured telephone number. Activation for all call types: <Telephone number> Activation for selected call type: <Telephone number> <Call type> Deactivation: Status check: 2N TELEKOMUNIKACE a.s., www.2n.cz 48/70...
  • Page 49 Activation for selected call type: <Telephone number> <Call type> Activation for all call types and specified delay time: <Telephone number> <Delay time> Activation for selected call type and specified delay time: <Telephone number> <Call type> <Delay time> Deactivation: 2N TELEKOMUNIKACE a.s., www.2n.cz 49/70...

  • Page 50: Call Waiting

    If the call waiting is activated the incoming call isn't refused if there is call in progress on EasyGate. If there is the other incoming call during connected call it will be indicated by tone. See 0. for multiple calls management. Activation: Deactivation: Status check: 2N TELEKOMUNIKACE a.s., www.2n.cz 50/70...

  • Page 51: Call Hold

    To place the active call on hold to have possibility to dial other outgoing call dial: To place all held calls to active calls and set up conference call dial: To connect the two calls (active and held) and disconnect the EasyGate from both calls dial: 2N TELEKOMUNIKACE a.s., www.2n.cz 51/70...

  • Page 52: Fax And Data Function

    GSM network and the connection is not successful. In this case it is possible to set the gateway using DTMF commands using device connected to FXS line. These commands can be used for data and fax routing to FXS line or serial line. 2N TELEKOMUNIKACE a.s., www.2n.cz 52/70...

  • Page 53: Supported Fax And Data Protocols

    V.32, V.22bis, V.22, Bell 212A and Bell 103. Maximal data rate is 56kbps. For connection between two modems is the data rate limited by the CSD data rate in GSM network, the maximum is 14,4kbps. 2N TELEKOMUNIKACE a.s., www.2n.cz 53/70...
  • Page 54 The data rate for GPRS connection is limited by actual speed of GPRS transfer in GSM network too. This speed is often affected by network load. 2N TELEKOMUNIKACE a.s., www.2n.cz 54/70...

  • Page 55: Sms Sending Input

    Do not use in life-supporting or property-protection applications because of the character of SMS service and EasyGate. The manufacturer shall not be liable for health and property damage incurred as a result of SMS sending failure. 2N TELEKOMUNIKACE a.s., www.2n.cz 55/70...

  • Page 56: Data Connection Using Usb Port

    The installation wizard usually configures the telephone connection of the network too. If you use manual installation, you have set it properly. Ask you GSM provider for Internet connection instructions because they can be different for each provider 2N TELEKOMUNIKACE a.s., www.2n.cz 56/70...

  • Page 57: Sms Sending And Receiving

    The SMS program is only blocked temporarily during outgoing call establishing and incoming call ringing. The same applies to PCManager monitoring. A message announcing that EasyGate is blocked is displayed during voice call establishing. No voice call can be made during CSD data connection. 2N TELEKOMUNIKACE a.s., www.2n.cz 57/70...

  • Page 58: List Of Supported At Commands

    GSM module. Do not use particularly: ATQ1 AT+CMUT= AT^SNFI= ATS3= AT+CMUX= AT^SNFM= ATS4= AT+CSCS= AT^SNFO= ATS5= AT^SAIC= AT^SNFPT= ATV0 AT^SM20= AT^SNFS= AT&C0 AT^SMSO= AT^SNFV= AT+IPR= AT^SNFA= AT^SNFW= AT+CFUN= AT^SNFD=   2N TELEKOMUNIKACE a.s., www.2n.cz 58/70...

  • Page 59: Sim Card Pin Protection

    Use the mobile phone to unblock the SIM card. A correctly entered PIN is stored in EasyGate's memory as if you had programmed it using the PCManager. The PIN will be entered automatically upon the next EasyGate power up. 2N TELEKOMUNIKACE a.s., www.2n.cz 59/70...

  • Page 60: Automatic Pin Entering

    There are still two manual PIN-entering attempts after such unsuccessful automatic entering. To prevent the unsuccessful automatic PIN entering, delete or program properly the EasyGate PIN using the PCManager in the case of SIM card change. 2N TELEKOMUNIKACE a.s., www.2n.cz 60/70...

  • Page 61: Technical Parameters

    CSD max. 14.4 kbps; Coding scheme CS 1, 2, 3, 4 Fax: Fax Group 3 on model with fax converter Antenna: 850/ 900/ 1800/ 1900 MHz 50 Ω SMA antenna connector SIM card: 3V or 1,8V plug-in 2N TELEKOMUNIKACE a.s., www.2n.cz 61/70...
  • Page 62 Dialing type: tone (DTMF) and pulse Ringing voltage: 42 Vrms 50/25 Hz Calling line identification: CLI during ringing according to ETSI FSK Tariff pulses: f=16/12 kHz ; Umin=100mVef on 200 Ω Answer supervision: polarity reversal, 12/16 kHz pulses 2N TELEKOMUNIKACE a.s., www.2n.cz 62/70...
  • Page 63 Other parameters Dimensions (w/o connectors): 163 x 157 x 38 mm Operating temperature: 0 ºC to 45 ºC Operating status signaling: 4 LEDs (on, GSM network, line, data) Signal / Battery status 2N TELEKOMUNIKACE a.s., www.2n.cz 63/70...

  • Page 64: Supplementary Information

    6. Supplementary Information This section describes supplementary information product. Here is what you can find in this section: 6.1 Troubleshooting 6.2 List of Abbreviations 6.3 Regulations and Directives 6.4 General Instructions and Cautions 2N TELEKOMUNIKACE a.s., www.2n.cz 64/70...

  • Page 65: Troubleshooting

    Check the COM number setting on PC. Check the COM parameters (1200-115200 bps, 8N1). EasyGate is not registered to GSM network. A dialing or outgoing call establishing process takes place on EasyGate. An incoming call is ringing on EasyGate. 2N TELEKOMUNIKACE a.s., www.2n.cz 65/70...

  • Page 66: List Of Abbreviations

    SMS Short Message Service, a term for the system and one unit (message) SW Software TTL Transistor-Transistor Logic - a standard digital technology defining voltage for levels 0 and 1 PSTN Public Switched Telephone Network 2N TELEKOMUNIKACE a.s., www.2n.cz 66/70...
  • Page 67 Commission Regulation (EC) No. 1488/94 as well as Council Directive 76/769/EEC and Commission Directives 91/155/EEC, 93/67/EEC, 93/105/EC and 2000/21/EC Directive 2012/19/EC of the European Parliament and of the Council of 4 July 2012 on waste electrical and electronic equipment. 2N TELEKOMUNIKACE a.s., www.2n.cz 67/70...

  • Page 68: General Instructions And Cautions

    The consumer shall, at its own expense, obtain software protection of the product. The manufacturer shall not be held liable and responsible for any damage incurred as a result of the use of deficient or substandard security software. 2N TELEKOMUNIKACE a.s., www.2n.cz 68/70...

  • Page 69: Electric Waste And Used Battery Pack Handling

    Make sure that the devices to be disposed of are complete. Do not throw battery packs into fire. Battery packs may not be taken into parts or short-circuited either. 2N TELEKOMUNIKACE a.s., www.2n.cz 69/70...
  • Page 70 2N TELEKOMUNIKACE a.s. Modřanská 621, 143 01 Prague 4, Czech Republic Phone: +420 261 301 500, Fax: +420 261 301 599 E-mail: sales@2n.cz Web: www.2n.cz v1.0 2N TELEKOMUNIKACE a.s., www.2n.cz 70/70...
