Operating instructions
Drive shaft V-belt
Operating sweeping

machine without

automotive power

— The traction motor is provided
with a mechanical parking brake.
! To be able to move the sweeper
without using its automotive
feature it is necessary to unlock
the brake.
! Pull the lever at the traction
motor to unlock the parking brake
KM 90/45 R
Fault instructions
Machine does not move
! Do not actuate pedal, turn key
switch to "0" and then back to "1"
! Charge the battery
! Check fuses
! Notify the Kärcher service station
Main brush or side brush does
not rotate
! Check if foreign objects, (tapes,
strings) jam the main brush or the
side brush
! Check fuses
! Notify the Kärcher service station
Machine not sweeping properly
! Check the main brush and the
side brushes
! Make the coarse dirt flap
movable
! Replace main brush/side brush
! Notify the Kärcher service station
Machine making dust
! Empty debris container
! De-dust or replace the dust filter
! Make the coarse dirt flap
movable
! Adjust or replace the sealing strip
! Clean filter box tunnel
! Replace profiled seal at filter box
tunnel
Poor sweeping around the edges
! Replacing the side broom
! Notify the Kärcher service station
Accessories
Instrument panel with multi-
functional display and integrated
operating hour
counter 4.841-128
Side brush 6.906-206
Provided with standard bristles for
indoor and outdoor surfaces.
Soft side broom 6.906-133
For fine dust on indoor surfaces,
resistant to moisture.
Hard side broom 6.906-065
For removing stubborn external dirt,
damp-proof.
Standard main
brush 6.906-028.0
Wearproof and wetproof.
Universal bristles for indoor and
outdoor cleaning.
Main brush soft 6.906-530.0
With natural bristles specially for
sweeping fine dust on smooth
indoor floors. Not moisture-resistant,
not for abrasive surfaces.
Main brush hard 6.905-923.0
For removing stubborn external dirt,
damp-proof.
Main brush 6.906-537.0
Antistatic
Flat pleated filter 5.731-585
Replace flat fold filters at least once
a year.
Wetproof, washable. Filter
efficiency > 99,9 %, corresponds to
category C of ZH 1/487 of BIA.
English
