(30) Multi-Function Output Terminal (RA-RB-RC or R1A-R1B-R1C) Function Selection (Sn-30)

(31) Multi-Function Output Terminal (DO1-DOG) Function Selection
(32) Multi-Function Output Terminal (DO2-DOG or R2A-R2C) Function Selection
Multi-function output terminal setting and its function as shown in Table 16.
Function
Setting
00 During running
01 Zero speed
02 Frequency agree
03 Setting frequency agree
Output frequency
04
detection1
Output frequency
05
detection2
06 Inverter ready
07 Undervoltage detected
08 Output baseblocked
09 Run source mode
10 Frequency command mode Ref. Cmd. Operator
11 Overtorque detected
Frequency command
12
Invalid
13 Fault
14 Pulse signal output
15 Undervoltage alarm
16 Inverter overheat
17 Motor overload
18 Inverter Overload
19 Fault retry
RS-485 communication
20
fault
21 Timer function output
RS-485 Communication
22
Application
Table 16 Multi-function output terminal function
LCD Display
Running ON：During running
Zero Speed
Frequency Arrive Speed agree width: Cn-31
Agreed F Arrive
Freq. Det. 1
Freq. Det. 2
Run Ready OK! ON：READY
Low Volt Detect ON：Undervoltage detected
Output B.B.
Run Source
Operator
Over Tq. Detect ON：Overtorque detected
Freq. Cmd. Invalid ON：Frequency command Invalid
Fault
Pulse Mul. Output Only set by Sn-31, Sn-32 (terminal DO1-DOG)
Low Volt Alarm ON：Undervoltage alarm
Inverter Over Heat ON：Inverter Overheat
Motor Over Load ON：Motor Overload
Inverter Over Load ON：Inverter Overload
Fault Retry
RS-485 Fault
Timer Function Signal delay output (.vs. timer function input)
Comm. Control
Description
ON：Zero speed
ON：output frequency = ±Cn-29,
Speed agree width: Cn-31
ON：while ACC, -Cn-29≧output freq.≧Cn-29
while DEC, -Cn-30≧output freq.≧Cn-30
Speed agree width: Cn-31
ON：while ACC, output freq≧Cn-29(or≦-Cn-29)
while DEC, output freq≧Cn-30(or≦-Cn-30)
Speed agree width: Cn-31
ON：Output baseblocked
ON： Run source from digital operator (Local mode)
ON：Frequency command from digital operator
(Local mode)
ON：Fault
ON：Retry
ON：RS-485 communication fault
Extension Output Contact application
(Please refer to '7200MA RS-485 MODBUS
/PROFIBUS Application Manual')
