Summary of Contents for TECO 7300EV

  • Page 2: Quick Start Guide

    Instruction Manual supplied with your inverter. Step 1 Before starting the inverter Please refer to chapter one (Preface) and chapter two (Safety Precautions) of the 7300EV Instruction Manual. Verify drive was installed in accordance with the procedures as described in chapter three (Environment description and installation). If you feel this was abnormal, do not start the drive until qualified personnel have corrected the situation.
  • Page 3 Press RUN Key, inspect the motor operation as motor accelerates to full load. Press STOP Key, inspect the motor operation as motor deceleration. Step5 Other settings As for other function, please refer to 7300EV user manual. Set acceleration time ………………………………… P. 4-9 Set deceleration time ………………………………… P. 4-9 Set upper frequency limit …………………………...

  • Page 4: Table Of Contents

    3.3.3 Precautions for peripheral applications…………………...… 3-10 3.4 Specification ………………………………………………………….. 3-13 3.4.1 Product individual specification..……………………………. 3-13 3.4.2 General specifications………………………………………… 3-14 3.5 7300EV wiring diagram………………………………………………. 3-16 3.6 Description of inverter terminal ..…………………………..……….. 3-17 3.7 Dimension ………………….…………………………………………. 3-20 3.8 Installation and design consideration……………………………….. 3-23...
  • Page 5 6.1 Input side AC reactor………………………………………………… 6.2 EMC filter……………………………………………………………. 6.3 Option card……………………………..………………………….… 6.3.1 RS-485 option card…………………..……………………… 6.3.2 RS-232 option card……………………………………..…… 6.3.3 Program copy option card………………………………….. 6.3.4 Remote keypad ……………………………………………….. 6.3.5 2 IN/1OUT Card ……………………………………………… 6-10 Appendix 1 7300EV inverter parameter setting list………………… Appendix 1...

  • Page 6: Chapter 0 Preface

    Should there be any problem in using the product and can not be solved with the information provided in the manual, contact your nearest TECO distributor or our sales representatives who will be willing to help you. Please keep using TECO’s products in the future. ※ Precautions The inverter is an electrical electronic product.

  • Page 7: Chapter 1 Safety Precautions

    Chapter 1 Safety Precautions Chapter 1 Safety Precautions 1.1 Operation Precautions 1.1.1 Before Power Up Caution The line voltage applied must comply with the inverter’s specified input voltage. Danger Make sure the main circuit connections are correct. L1(L), L2, and L3(N) are power-input terminals and must not be confused with T1, T2 and T3.

  • Page 8: During Power Up

    Chapter 1 Safety Precautions 1.1.2 During Power up Danger The inverter still has control power if the time of power loss is very short. When the power is re-supplied, the inverter operation is controlled by F41. The inverter operation is controlled by F04 and C09 and the status of (FWD/REV RUN switch) when power is re-supplied.

  • Page 9: During Operation

    Chapter 1 Safety Precautions 1.1.5 During operation Danger Do not connect or disconnect the motor while inverter is operating the motor, Otherwise the inverter and the diconnect device will be damaged by the high level of switch off current. Danger To avoid electric shock, do not take the front cover off.
  • Page 10 Chapter 2 Model description Model:JNEV-201-H1 Inverter model I/P:AC 1 PH Input power 200-240V 50/60Hz O/P:AC3PH 0~264V 1.6KVA 4.2A Output power TECO ELECTRIC ＆ MACHINERY CO.,LTD JNEV Input Max suitable motor Series: SPEC.: Power supply : Noise filter : Enclosure voltage :...

  • Page 11: Chapter 3 Environment Description And Installation

    Chapter 3 Environment description and installation Chapter 3 Environment description and installation 3.1Environment The environment will directly affect the proper operation and the life of the inverter, so install the inverter in an environment complies with the following conditions: Ambient temperature: -10 ℃...
  • Page 12 Chapter 3 Environment description and installation The chassis of this model has DIN-RAIL device to use with aluminum rail. This model also can be installed Side by Side (with inside temperature below 50 ℃...
  • Page 13 Chapter 3 Environment description and installation EV-1P2/1P5/101/2P2/2P5/201- -N4X(IP65 TYPE INSTALLATION : (PE) NOTE : (PE) 1. POWER SWITCH , REV-0-FWD SWITCH AND Potentiometer are only for EV-1P2~201- N4S TYPE 2. Power supply cable : #14 AGE (2.0m ) 3. Motor cable : #16 AGE (1.25m ) 4.
  • Page 14 Chapter 3 Environment description and installation EV-1P2/1P5/101/2P2/2P5/201- -N4S install :...
  • Page 15 Chapter 3 Environment description and installation EV-1P2/1P5/101/2P2/2P5/201- -N4 install :...

  • Page 16: Environment Precautions

    Chapter 3 Environment description and installation 3.2 Environmental precautions Do not use the inverter in an environment with the following conditions: Direct sunlight Corrosive gas and liquid Wind, rain, and water Salt Iron filings, dust drops may get into Excessive high Extreme low temperature Excessive vibration temperature...

  • Page 17: Wiring Rules

    Chapter 3 Environment description and installation 3.3 Wiring Rules 3.3.1 Notice for wiring Screwdriver torque: Connect cables with a screwdriver or other suitable tools and follow the torque listed below. Securing torque Horsepower Power source Nominal torque for TM1 terminal 0.25/0.5/1 100-120V 0.74/0.1...
  • Page 18 The drive’s electronic protection circuitry is designed to clear drive output short circuits and ground faults without blowing the drive input fuses. Below table shows the 7300EV input fuse ratings. To protect the inverter most effectively, use fuses with current-limit function.

  • Page 19: Suitable Mc, Mccb, Fuse And Wire Specification

    3.3.2 Suitable MC, MCCB, Fuse and wire specification. MCCB/ MC/ Fuse TECO warranty and replacement service will not apply under following condition. (1)MCCB or fuse is not installed or unsuitably installed or installed with over capacity, which has resulted in inverter fault.

  • Page 20: Precautions For Peripheral Applications

    Chapter 3 Environment description and installation 3.3.3Precautions for peripheral applications: Power supply: Make sure the voltage applied is correct to avoid damaging the inverter. A molded-case circuit breaker must be installed between the AC source and the inverter. Molded-case circuit breaker: Use a molded-case circuit breaker that conforms to the rated voltage and current of the inverter to control the power ON/OFF and protect the inverter.
  • Page 21 (A) Main circuit must be separated from other high voltage or high current power line to avoid noise interference. Refer to following figures: The inverter uses dedicated power line A general noise filter may not provide rightful results Power 7300EV Power 7300EV Please added a noise filter or separation General Machine...
  • Page 22 Chapter 3 Environment description and installation The supply and output ( PE) terminals have to be connected to ground to increase noise immunity of the Filter. Ground (A)The control circuit wire and main circuit wire/ other high voltage power wire or high current power wire should be separated to avoid noise interruption.

  • Page 23: Specification

    Chapter 3 Environment description and installation 3.4 Specification 3.4.1 Product individual specification 100V model 200V model Model □□□ □□□ □□□ -H1(F) 2P2 2P5 201 202 203 2P2 2P5 Horse power (HP) 0.25 0.25 0.5 0.25 Suitable motor capacity (KW) 0.2 0.75 0.4 0.75 1.5 0.75 1.50...

  • Page 24: General Specifications

    Chapter 3 Environment description and installation 3.4.2 General Specifications Range 0~200Hz Initial Drive 100%/3Hz (Vector mode) Speed Control Range 1:50(Vector mode) Speed Control ±0.5%(Vector mode) Precision Setting resolution ※1 Digital: 0.1Hz(0~99.9Hz)/1Hz(100~200Hz); analog: 0.06Hz/ 60Hz Keypad setting Set directly with keys or the VR on the keypad Indication 7 segment*3 Displays frequency/DC Voltage/Output Voltage / function...
  • Page 25 Chapter 3 Environment description and installation Over load protection Inverter rated current 150%/1min International UL/CE conformity Over voltage 200V Class: DC voltage >400V 400V Class: DC voltage >800V Under voltage 200V Class: DC voltage <190V 400 Class: DC voltage <380V Instantaneous power Set to enable or disable loss restart...

  • Page 26: 7300Evwiring Diagram

    Chapter 3 Environment description and installation 3.5 7300EVWiring diagram Braking Unit Power terminal Single phase 100~120V • L1(L) 1/3 phase 200~240V • 3 phase 380~480V • L3(N) (3)24V RA(1) PNP common point Multi-function digital output (4)S1 RB(2) Multi function digital (5)S2 input (6)S3...

  • Page 27: Description Of Inverter Terminal

    Chapter 3 Environment description and installation 3.6 Description of Inverter Terminal Descriptions of power terminals Symbol Description L1 ( L ) Main power input Single-phase: L/N Three-phase: L1/L2/L3 L3 ( N ) DC power and braking unit connect terminals, applied in large load inertia or short deceleration time and inverter tender to trip.
  • Page 28 Chapter 3 Environment description and installation Control signal terminals block description 1 2 3 7 8 9 10 11 12 Symbol Description Rated contact capacity: Multi-functional output terminal (250VAC/10A) Normally open contact Contact description: (refer to F21) Supply for external potentiometer for speed reference. Analog frequency signal input terminal or multi-function input terminal S7 (high level :upper than 8V/low level: lower than 2V,adapt to PNP (refer to F15 description)
  • Page 29 Chapter 3 Environment description and installation SW function description Type of external signal Remarks NPN input (SINK) PNP input (SOURCE) Factory default Type of external signal Remarks 0~10V DC analog signal Effective when external F05=2 4~20mA analog signal 3-19...

  • Page 30: Dimension

    Chapter 3 Environment description and installation 3.7 Dimension (1) IP20 Frame1: Single phaseJNEV-1P2~201-H1/H1F Three phaseJNEV-2P2~201-H3 3-20...
  • Page 31 Chapter 3 Environment description and installation (2) IP20 Frame2: Single phaseJNEV-202~203-H1/H1F Three phase JNEV-202~203-H3 Three phase JNEV-401~403-H3/H3F Unit: mm/inch LENGTH MODEL Frame 1 132/5.2 123.5/4.86 67/2.64 77/3.03 Frame 2 132/5.2 123.5/4.86 108/4.25 118/4.65 LENGTH MODEL Frame 1 130.5/5.13 128.45/5.06 8/0.315 Frame 2 148/5.83 144/5.67...
  • Page 32 Chapter 3 Environment description and installation (3) IP65 Frame1(switch) EV-1P2/1P5/101/2P2/2P5/201-N4S(IP65 type)： IP65 Frame1(no switch) EV-1P2/1P5/101/2P2/2P5/201-N4(IP65 type)： 3-22...

  • Page 33: Installation And Design Consideration

    Chapter 3 Environment description and installation 3.8 Installation and design consideration must power on the same time (On the same power system permit bus parallel connection) Built in braking resistor bus link Mutually absorb voltage to strengthen brake capacity as multi-units parallel connect When brake is not enough as parallel connected, add in...

  • Page 34: Chapter 4 Programming Instructions & Parameter List

    Chapter 4 Software index Chapter 4 Programming instructions & Parameter list 4.1Keypad description 4.1.1 Keypad display and operation instruction Power LED (Red) 4.1.2Operation Instruction of the keypad F10=001, inverter displays status F × × Power ON DATA Display frequency in stop F ×...
  • Page 35 Chapter 4 Software index Remote/Local change function • Local mode Run command only RUN/STOP pad on the keypad can control and Run parameter ● (F04) don’t care Frequency command ● When C41=000: only UP/DOWN pad on the keypad can control and F05 setting have no relationship.

  • Page 36: Parameter Function List

    Chapter 4 Software index 4.2 Parameter function list Basic parameter function list Factory Function Description Range/ Code Remarks Default 00 Inverter horse power code 01 Acceleration time 1 00.1~999s 05.0 *1 *2 02 Deceleration time 1 00.1~999s 05.0 *1 *2 000: Forward 03 Motor rotating direction 001: Reverse...
  • Page 37 Chapter 4 Software index 000: Positive 19 AIN Bias 001: Negative 000: Positive 20 AIN .Slope Direction 001: Negative 000: In running 001: Frequency reached (Set frequency ± F23) 002: Frequency is within the range set by (F22±F23) 003: Frequency Detection (>F22) 004: Frequency Detection (<F22) 005: Fault terminal 006: Auto reset and restart...
  • Page 38 Chapter 4 Software index 39 DC braking level 000~020% 40 Carrier frequency 004~016 4~16K Restart for momentary 000: Enable power loss 001: Disable 42 Auto-restart times 000~005 43 Motor rated current 44 Motor rated voltage 45 Motor rated frequency 46 Motor rated power 47 Motor rated speed 48 Torque Boost Gain (Vector) 001~450 Slip Compensation Gain...
  • Page 39 Chapter 4 Software index *1 *2 11 Acceleration time 2 00.1~999 Sec 05.0 *1 *2 12 Deceleration time 2 00.1~999 Sec 05.0 This function only available 000: Auto-run by inverter temperature for IP20 type, 001: Run when inverter running For IP65 13 Fan control 002: Always run type , fan will...
  • Page 40 Chapter 4 Software index 33 I: Integral time (s) 00.0 – 100 10.0 34 D: Differential time (s) 0.00 – 10.0 0.00 000: Positive direction 35 PID OFFSET 001: Negative direction 36 PID OFFSET adjust (%) 000 – 109 37 PID postpone time (s) 00.0 - 02.5 00.0 38 PID Sleep starting level 00.0~200Hz...
  • Page 41 Chapter 4 Software index 000: In running 001: Frequency reached (Set frequency ± F23) 002: Frequency is within the range set by (F22±F23) 003: Frequency detection (>F22) 004: Frequency detection (<F22) 005: Fault terminal Multi-function output 006: Auto-restart (option) 007: Momentary power loss T+，T- 008: Emergency Stop(E.S.
  • Page 42 Chapter 4 Software index Note: *1: Can be modified in Run mode. *2: Frequency resolution is 1Hz for settings above 100 Hz. *3: Cannot be modified during communication. *4: Do not change while making factory setting. F52 factory setting is 020(60HZ) and motor parameter value is 170. F52 factory setting is 010(50HZ) and motor parameter value is 140.

  • Page 43: Parameter Function Description

    Chapter 4 Software index 4.3 Parameter function description Basic function parameter list F00 Inverter horse power code Inverter model Inverter model JNEV JNEV F01 Acceleration time 1 (s): 00.1 – 999 F02 Deceleration time 1 (s): 00.1 – 999 Formula for acceleration/deceleration time: Denominator is based on (factory setting is Sensor less vector control) a) Motor rating frequency ( Sensor less vector control).
  • Page 44 Chapter 4 Software index 2.) F5=002,when one of parameter group F11~ F15 is set to 015 and multi-function input terminal is OFF, the frequency is set by analog signal (auxiliary speed) from TM2. If the multi-function input terminal ON, the frequency is set by VR on Keypad. 3.) Up/Down terminal: please refer to description of parameter group F11~ F15(multi-function input terminal).
  • Page 45 Chapter 4 Software index ※Note: C00=001, reverse command is disable. F07 Frequency upper limit (Hz) : 01.0 - 200 F08 Frequency lower limit (Hz): 00.0 - 200 F07 (Frequency upper limit) ( ••••• F08 (Frequency lower limit) d Frequency Comman ※Note: If F07 = 0 Hz and frequency command = 0 Hz, the inverter will 0-speed stop.
  • Page 46 Chapter 4 Software index F11~15 Selectable Functions for input trerminals ( S1-S4& AIN ) 000: Forward Run 001: Reverse Run 002: Preset Speed Command 1 003: Preset Speed Command 2 004: Preset Speed Command 3 005: Jog frequency Command 006: Emergency stop(E.S.) 007: Base Block (b.b.) 008: Switching to 2nd acceleration/ deceleration time 009: Reset...
  • Page 47 Chapter 4 Software index F11~F15=006: Emergency Stop(E.S) The inverter will decelerate to stop on receiving the external emergency stop signal. The display will be blinking with E.S. The inverter will only start again when the Emergency Stop signal is removed and the start signal is turned off and then on again (remote start mode) or the Run key is pressed in ( keypad mode).
  • Page 48 Chapter 4 Software index Run signal Acceleration ※ Note: Acceleration/deceleration prohibit is /deceleration unavailable as Run signal is OFF. prohibit Output frequency F11~F15=015 Master/Auxiliary speed switch 1) F05=001，when one of the parameters F11~ F15 is set to 015, and multi-function input terminal is OFF, the frequency is set by the VR on the Keypad(Master speed);...
  • Page 49 Chapter 4 Software index F17 AIN Gain (%) 000 - 200 F18 AIN Bias (%) 000 - 100 1.) F19= 000: 0V (4mA) corresponding to lower frequency limit, 10V (20mA) corresponding to upper frequency limit. 2.) F19= 001: 10V (20mA) corresponding to lower frequency limit, 0V (4mA) corresponding to upper frequency limit.
  • Page 50 Chapter 4 Software index F19 AIN Bias: 000: Positive 001: Negative F20 AIN Signal Slope direction. 000: Positive 001: Negative C45 AIN signal scan time confirmation. (mSec × 8): 001 – 100 Refer to F17/F18 description The inverter reads A/D average value every C45 x 8mS. The user can set scan interval time according to noise in the operation environment.
  • Page 51 Chapter 4 Software index F21/C46=002 Preset output Frequency F22 ± F23 r eached. F21/C46=003: Frequency detection Fout>F22 4-18...
  • Page 52 Chapter 4 Software index F21/C46=004: Frequency detection Fout﹤F22 F24 Output current reach setting value F25 Output current detection time F21: Output current detection value >F24 When setting value is 015 C46: Output current detection value >F24 F24: Setting value (000~100%) by motor rated current (F43) F25: Setting value (00.0~25.5) unit : sec load 4-19...
  • Page 53 Chapter 4 Software index Multi-function analog output: F26 Multi-function output analog type selection 001: Set frequency 002: Output frequency 003: DC voltage 004: Output current 005:PID feedback signal F27 Multi-function analog output gain = 000 ~ 200% 0-10 Vdc output from FM+ multi-function analog output terminal. Output can be set to any of the above selections.
  • Page 54 Chapter 4 Software index Frequency read priority: Jog Preset frequency External analog frequency signal Preset Preset Preset Jog frequency Frequency Frequency Frequency Output Command Command 3 Command 2 Command 1 frequency Set value =005 Set value =004 Set value =003 Set value =002 F37 DC braking time (s) ：...
  • Page 55 Chapter 4 Software index Corresponding list of current and carrier frequency Model EV-1P2/2P2 EV-1P5/2P5 EV-101/201 EV-202 EV-203 EV-401 EV-402 EV-403 Carrier H1/H1F/H3 H1/H1F/H3 H1/H1F/H3 H1/H1F/H3 H1/H1F/H3 H3/H3F H3/H3F H3/H3F frequency 4~10K 10.5 10.5 F41 Auto restart on momentary power loss. 000: Enable 001: Disable F41=000: Auto restart after a momentary power loss is enabled on resumption of power and application of run signal, according to setting of parameter F4.
  • Page 56 Chapter 4 Software index • Torque/Speed curve pattern: Torque ΔTe： Increase output torque capacity • Operating frequency range: 0~Motor rate frequency • When the motor output torque is not enough and increase F48 setting value. • When the motor is vibration or tremble and decrease F48 setting value. •...
  • Page 57 Chapter 4 Software index F50 Low frequency voltage compensation, C14=000 Performance: During low frequency Increase F50 setting value can increase output voltage and low frequency torque. Decrease F50 setting value can decrease output voltage and low frequency torque. • Output voltage/frequency curve pattern: 0~12HZ / 60HZ •...
  • Page 58 Chapter 4 Software index C01 Acceleration stall-prevention: =000: Enable Stall prevention during Acceleration. =001: Disable Stall prevention during Acceleration. C02 Acceleration stall-prevention level: 050% ~ 200% C03 Deceleration stall-prevention: = 000: Enable Stall prevention during deceleration. = 001: Disable Stall prevention during deceleration. C04 Deceleration stall-prevention level: 050% ~ 200% C05 Run stall-prevention: = 000: Enable Stall prevention in Run mode.
  • Page 59 Chapter 4 Software index 000: Reset is enable when RUN switch is in OFF position. C10 Reset mode 001: Reset is enable with RUN switch, either OFF or ON . C10=000. Fault can not be reset, therefore inverter can not start. If the RUN switch is in ON position. （F4=001）...
  • Page 60 Chapter 4 Software index C15 = 001– 006 fixed V/F pattern (refer to following table). C15 V/F Pattern C15 V/F Pattern Spec Spec 4-27...
  • Page 61 Chapter 4 Software index C16 VF base output voltage set As C17=60HZ C18=100% If C16 setting 200~240V, then output voltage for the pattern: C16=240 C16=220 C16=200 60.0Hz (C17) When the output voltage is higher than the input voltage and the max. output voltage limit to the max.
  • Page 62 Chapter 4 Software index C30 PID operation mode 000: PID Function disabled. 001: PID Control, Deviation is derivative controlled 002: PID Control, Feedback id derivative controlled. 003: Same as 001 but (reverse characteristics control). 004: Same as 002 but (reverse characteristics control). C30 =1, D is the deviation of (target value –...
  • Page 63 Chapter 4 Software index C37 PID postpone time (s): 00.0 - 02.5 C37: the refresh time of PID output command. ※Note: PID function is used in flow control, external fan wind volume control and temperature control. And the control flow is as the following figure: 1.
  • Page 64 Chapter 4 Software index Timing diagram is as following: C40 Frequency Up/Down control using MFIT : 000: When using Up/Down command, the set frequency by this function will be stored as the inverter stops. UP/DOWM function is not available in stop mode. 001: When using Up/Down command, the set frequency will be reset to 0Hz as the inverter stops.
  • Page 65 Chapter 4 Software index Load /Remote control select explain • Locad mode Run command Only Run/Stop pad on the keypad can control and F04 setting have no relationship. Frequency command When C41=000: only UP/DOWN pad on the keypad can control and F05 setting have no relationship.
  • Page 66 Chapter 4 Software index C46 (Option card) Multi-function output T+，T- 000: In running 001: Frequency reached [Preset target frequency ± F23] 002: Frequency reached [ Preset output frequency level (F22) ±F23] 003: Frequency detection (>F22) 004: Frequency detection (<F22) 005: Fault . 006: Auto-restart 007: Momentary power loss 008: Emergency Stop (E.S.)
  • Page 67 The inverter will validate the modified parameters after the parameters modified by PC. c. Communication protocol: refer to 7300EV communication protocol description. d. Parameter C49~C53 can’t be change under communication mode.
  • Page 68 Chapter 4 Software index C54/C55 Communication error parameter timing pattern Master T3 > C54 Slaver (EV)Tx F21=014 或 C46=014 0,1,2 ( 3) Frequency Dec from F02 C55=000 or 002 If F02 ＜ C12 Dec from C12 Frequency free Run C55=001 Frequency keep Run Display show “COT”...

  • Page 69: Chapter 5 Troubleshooting And Maintenance

    Chapter 5 Trouble shooting and maintenance Chapter 5 Troubleshooting and maintenance 5.1Trouble indication and remedy 5.1.1 Fault/ Error display and Diagnostics 1. Un- resetable / un recoverable Errors Display Error Cause Remedy EEPROM EEPROM problem Change EEPROM problem Over voltage during Detection circuit malfunction Send the inverter back for repair stop 1.
  • Page 70 Chapter 5 Trouble shooting and maintenance 2. Errors which can be recovered manually and automatically Display Error Cause Remedy 1.The motor winding and 1.Check the motor frame short circuit 2.Check the wiring Over current at 2.Motor and ground short circuit 3.Replace the power module start 3.Power module is damaged...
  • Page 71 Chapter 5 Trouble shooting and maintenance 3. Errors which can only be recovered manually but cannot be auto-recovered Display Error Cause Remedy 1. Detection circuit malfunctions Send the inverter back for Over-current 2. Bad connection for CT repair during stop signal cable 1.

  • Page 72: Set Up& Interface Errors

    Chapter 5 Trouble shooting and maintenance 5.1.2 Set up& Interface Errors. Display Error Description Zero speed stop It happens as set frequency <0.1Hz 1. If the inverter is set to external control mode (F04=001), and direct start is disabled (C09=001), the inverter cannot be Fail to start started and will flash STP1 when Run switch is in ON directly...

  • Page 73: Keypad Operation Error Description

    Chapter 5 Trouble shooting and maintenance 5.1.3 Keypad operation error description Display Error Cause Remedy 1. Press keys when keys can be used F05> 0 or in speed to modify frequencies only operation. when F05=0. 2.Attempt to modify 2. Modify them after stop. Key operation parameters, which can not error...

  • Page 74: General Functional Troubleshooting

    Chapter 5 Trouble shooting and maintenance 5.2 General functional troubleshooting Status Checking point Remedy • Is the power applied? Turn the power OFF and then ON • again. Is power applied to L1, L2, and L3(N) Make sure the power voltage is •...

  • Page 75: Troubleshooting Flowcharts 7300Ev Series

    Chapter 5 Trouble shooting and maintenance 5.3 Troubleshooting Flowcharts 7300EV Series 7300EV INV faults Is failure fully understood? Any symptoms Symptoms other than burn out, Check burnt and damaged of burnout and parts damage, or fuse meltdown in damage? the inverter?
  • Page 76 Chapter 5 Trouble shooting and maintenance * to previous page Check parameters of the inverter Perform parameter initializations Specify operation control method Set up frequency commands Is the frequency value displayed in Replace the control board the operating unit Are there voltage outputs in output Replace the control terminals T1,T2...
  • Page 77 Chapter 5 Trouble shooting and maintenance Troubleshooting for OC, OL error displays The inverter displays OC, OL errors Is the main circuit I.G.B.T. working Replace I.G.B.T properly? abnormalities in Replace faulty circuit boards appearances? Apply the power Any abnormal Is the current indications? detector OK? Replace the current sense...
  • Page 78 Chapter 5 Trouble shooting and maintenance Troubleshooting for OV, LV error display The inverter displays OV. LV Is the main circuit fuse Replace the main circuit board intact? Apply the power Abnormal error Replace the control board code Input operation commands Input frequency commands Is the output frequency of the operating unit...
  • Page 79 YES (normal value locates inside 3%) The voltage ˙ power abnormal between ˙ wiring incorrect are correct? ‘LED indicator 7300EV fault lit? Is the operation The operation switch is set to switch in RUN “RUN” position position? Is there...
  • Page 80 Chapter 5 Trouble shooting and maintenance Motor is overheated Is the load or the Reduce the load current exceeding the Increase capacities of 7300EV and specified value? the motor Is it running in low speed for a Select the motor again...

  • Page 81: Routine And Periodic Checks

    Chapter 5 Trouble shooting and maintenance 5.4 Routine and periodic checks To ensure stable and safe operations, check and maintain the inverter regularly and periodically. The table below lists the items to be check to ensure stable and safe operations. Check these items 5 minutes after the “Charge”...

  • Page 82: Maintenance And Inspection

    (a) Disconnect all leads connecting 7300EV with external circuit when performing insulation tests against external circuit. (b) Internal insulation test should be performed against the main circuit of the 7300EV inverter only. Use a high resistance DC 500V meter with insulating resistance higher than 5M .

  • Page 83: Chapter 6 Peripherals Components

    Chapter 6 Peripherals Chapter 6 Peripherals Components 6.1 Input side AC reactor Model input side AC inductance Current (A) inductance (mH) 2P2/2P5-H1(F)/H3 201-H1(F)/H3 202-H1(F)/H3 19.0 203-H1(F)/H3 25.0 0.71 JNEV-XXX- 401- H3(F) 402- H3(F) 403- H3(F) 6.2 EMC filter The inverter adopts rapid switching components to improve the efficiency of the motor and to reduce the motor noise.
  • Page 84 Chapter 6 Peripherals Filter selection: Build in Filter model Option Filter model (First Environment (First Environment Inverter model Rated (INPUT) Unrestricted Distribution./ Unrestricted Distribution./ Restricted Distribution.) Restricted Distribution.) JNFS21017-20.8-07 1P2-H1 1 85 ~132V (Restricted Distribution.) JNFS21017-20.8-07 1P5-H1 1 85 ~132V (Restricted Distribution.) JNFS21017-20.8-07 101-H1...
  • Page 85 Chapter 6 Peripherals 7300EV EXTERNAL FILTER SIZE JNFS21017-20.8-07 FOR EV-1P2~201-H1 JNFS21019-8.9-07 FOR EV-2P2~201-H3...
  • Page 86 Chapter 6 Peripherals JNFS21015-22-07 FOR EV-202~203-H1 JNFS21016-15-07 FOR EV-202~203-H3...
  • Page 87 Chapter 6 Peripherals JNFS20858-7-07 FOR EV-401~403-H3...

  • Page 88: Option Card

    Chapter 6 Peripherals 6.3 Option card 6.3.1 RS-485 option card (Model: JNSIF-485 ) Red cable to 24V Black cable to COM JNSIF-485 wiring diagram: ※ Note : In order to avoid external static electricity interfere with option card function, please cover the up cover to the main unit as all option card served.

  • Page 89: Rs-232 Option Card

    Chapter 6 Peripherals 6.3.2 RS-232 option card (model: JNSIF-232 ) JNSIF-232 wiring diagram L1 (L) SINGLE/THREE-PHASE POWER SUPPLY L3 (N) 7300EV SERIES RS-232 INVERTER CON302 (12P) JNSIF-232 1.8 m...

  • Page 90: Program Copy Option Card

    Chapter 6 Peripherals 6.3.3program copy option card (Copy Unit) (model: JNSIF-MP) JNSIF-MP Wiring diagram SINGLE/THREE-PHASE L1 (L) POWER SUPPLY L3 (N) 7300EV SERIES INVERTER Copy Unit CON302 (12P) JNSIF-MP...

  • Page 91: Remote Keypad

    Chapter 6 Peripherals 6.3.4 Remote keypad (Remote keypad)( Model: JNSDOP-LED-2M ) Red cable to 24V Black cable to COM JNSDOP-LED-2M wiring diagram ※ When the inverter is power on or off can set up or remove the remote keypad, but must connect TM2 24V DC power will normal use.

  • Page 92: In/1Out Card

    Chapter 6 Peripherals 6.3.5 2 In/1 Out card(model: JNSIF-IO ) Red cable to 24V Black cable to COM JNSIF-IO wiring diagram CON302(12P) 6-10...

  • Page 93: Appendix 1 7300Ev Inverter Parameter Setting List

    Appendix Appendix 7300EVinverter parameter setting list Customer Name Model of the inverter: Location of use: Customer’s telephone number: Customer’s address: Parameter Parameter Parameter code Setting Setting Setting code code Appendix Ι...
