•During Running (Setting:00)

OFF Run source OFF, inverter is off.
ON Run source ON, or Run source OFF but residues output exists
•Zero Speed (Setting：01)
OFF Output frequency ≧ MIN. output frequency (Cn-07)
Output frequency ＜ MIN. output frequency (Cn-07)
ON
•Frequency Agree :
•Setting Frequency Agree :
•Output Frequency Detected 1 : (Setting：04)
•Output Frequency Detected 2 : (Setting：05)
•Refer frequency detection function on page 55.
•Inverter Ready (Setting：06)
•Undervoltage Detected (Setting：07)
• When the DC link voltage of main circuit is lower than the UNDERVOLTAGE
DETECTION LEVEL (Cn-39), the output contact is in 'ON' state.
•Output Blocked (Setting：08)
•Run Command Mode (Setting：09)
Remote Mode
(Sn-04 = 1,2, or multi-function input terminal
OFF
mode or Local/remote control II mode and contact terminal is OFF). Remote-SEQ LED
is light in LCD digital operator
Local Mode
(Sn-04 = 0 multi-function input terminal
ON
and contact terminal is ON).Remote-SEQ LCD is OFF, run command is from LCD
digital operator
•Frequency Command Mode (Setting：10)
Remote mode
(Sn-05 = 1,2，or multi- function input terminal
OFF
mode or Local/remote control II mode and contact terminal is OFF). Remote-REF LED
is light in LCD digital operator
Local mode
(Sn-05 = 0 multi- function input terminal
ON
and contact terminal is ON). Remote-REF LED is OFF, run command is from LCD
digital operator
(Setting：02)
(Setting：03)
~
~
90
~ is set as Local/remote control I
is set as Local/remote control I mode
~ is set as Local/remote control I
is set as Local/remote control I mode
