Chapter 5. SmartPAC 2 Program Mode

This chapter shows you how to make settings in SmartPAC 2 Program mode. Program
settings, which are entered via the Main Program Menu (see Figure 5-1), control SmartPAC 2
operation for an individual tool. (You make settings that control operation of all tools in
Initialization mode–see Chapter 4).
(Includes some options. Your display may look different.)
The following sections show you how to create, program, modify, delete, and load individual
tools. You are instructed how to enter tool names, set counters, and make settings for
programmable cams, die protection sensors, and other SmartPAC 2 options.
Once you have programmed and loaded a tool, you can switch to Run mode to run that tool on
your press (refer to Chapter 6). In Run mode, you can also make some adjustments to tool
settings.
If you need help using the SmartPAC 2 keyboard to input information on Program mode
displays, refer to Chapter 3.

Entering and Exiting Program Mode

NOTICE
SELECT = HIGHLIGHT + ENTER
When this manual instructs you to select an item, you should highlight the item, and press ENTER.
Follow the instructions shown in Table 5-1, page 5-2 to enter and exit Program mode. See
Figure 3-25, page 3-19 for help in navigating in Program mode
Program Mode
Figure 5-1. Main Program Menu
