Each batch counter is assigned to a specific ProCamPAC channel: Batch 1 to Channel 6,
Batch 2 to Channel 7, and Batch 3 to Channel 8. If you set a Batch counter to either
TOGGLE or PULSE, the ProCamPAC channel controlled by that counter is displayed on
the Counters screen (see Figure 5-11).
The crankshaft angle at which Strokes, Good Parts, Total Hits, and Batch counters is
incremented can also be programmed.

Setting Preset Values

Counter presets specify the count at which SmartPAC 2 initiates one of three programmed
actions (i.e., Top-stop, Toggle, or Pulse). To enter counter presets, do the following:
On the Tool Program Menu, select COUNTERS to display the Counters screen.
1.
If this display appears, you need to enter the general password to program preset values.
Security access is set in Initialization mode (see SECURITY ACCESS, page 4-24).
Select the setting displayed in the PRESET VALUE column of the counter you want to
2.
program. The Numeric Entry window (see Figure 5-3, page 5-3) displays.
Key in a preset value, following the directions in the window, and press ENTER. The
3.
value you entered displays in the PRESET VALUE field for the counter you selected in
step 2.
NOTICE
You can disable a counter by setting its preset value to zero.
Repeat steps 2 and 3 for each counter preset you want to program.
4.

Changing Count Values

Under some circumstances, you may need to adjust the count upward or downward, or you
may want to start the count at some value other than zero. To change count settings, do the
following:
Program Mode
ENTER YOUR PASSWORD
USE THE KEYPAD TO ENTER NUMBERS.
USE THE UP/DOWN CURSON KEYS TO
INCREASE/DECREASE. PRESS ENTER
WHEN DONE. PRESS RESET TO CANCEL.
Figure 5-12. "Enter Your Password" Screen
60599
1126700
5-11
