Wintriss SmartPAC Instruction Sheet

Hide thumbs
Table of Contents

Advertisement

Quick Links

Instruction Sheet - Upgrading from
Original SmartPAC or SmartPAC 2 to
SmartPAC PRO
This document shows you how to replace your existing original SmartPAC (SmartPAC 1) or
SmartPAC 2 with SmartPAC PRO.
Refer to your SmartPAC PRO Installation Manual (1143200), as needed.
Checking That Mounting Location Can Accommodate SmartPAC PRO ....................................... 1
Recording SmartPAC Initialization Settings Before Upgrading ..................................................... 2
Backing Up the Tools on Your Existing SmartPAC ........................................................................ 2
Removing Your Existing SmartPAC ............................................................................................... 3
Mounting Your SmartPAC PRO ..................................................................................................... 4
Mounting Your Control Enclosure SmartPAC PRO ......................................................................................... 4
Mounting Your Panel Mount SmartPAC PRO .................................................................................................. 4
Terminating Cable Shields ............................................................................................................... 4
Wiring Your SmartPAC PRO .......................................................................................................... 4
Restoring (Copying) Tools to the SmartPAC PRO ......................................................................................... 12
Installing SBR on Your Laptop ..................................................................................................... 17
Connecting Your Laptop to SmartPAC ......................................................................................... 18
Backing Up Tools .......................................................................................................................... 19
Responding to Errors That Interrupt Processing ............................................................................ 25
Responding to a Checksum Error .................................................................................................. 27
Checking That Mounting Location Can Accommodate
SmartPAC PRO
The SmartPAC PRO control enclosure and panel mount are larger than the control enclosure and
panel mount models of original SmartPAC and SmartPAC 2.
Before you start the process of upgrading to a SmartPAC PRO, make sure the mounting location has
enough space. See your SmartPAC PRO Installation Manual for the space required to install
SmartPAC PRO, either control enclosure or panel mount, including clearance required in front of or
behind the mounting surface:
•
Control enclosure: 18 in. (457 mm) clearance required in front of the mounting surface
•
Panel mount: 6 in. (152 mm) clearance required behind the mounting surface
NOTICE
If the existing installation location provides insufficient space, find another location for the
SmartPAC PRO. Follow the guidelines in your SmartPAC PRO Installation Manual.
Instruction Sheet
Upgrading from Original SmartPAC or SmartPAC 2 to SmartPAC PRO
Wintriss Controls Group
April 2020
978-268-2700
1145200
Revision A
toll free 800-586-8324
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SmartPAC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wintriss SmartPAC

Summary of Contents for Wintriss SmartPAC

  • Page 1: Table Of Contents

    SmartPAC and SmartPAC 2. Before you start the process of upgrading to a SmartPAC PRO, make sure the mounting location has enough space. See your SmartPAC PRO Installation Manual for the space required to install...

  • Page 2: Recording Smartpac Initialization Settings Before Upgrading

    This information is stored at the PAC). Backing Up the Tools on Your Existing SmartPAC Use one of the methods below to back up (copy) the tool settings from your existing SmartPAC. • If your existing unit is a SmartPAC 2 with the BACKUP/RESTORE installed option, back up (copy) the tools onto a USB drive according to Using the SmartPAC 2 USB Disk BACKUP/RESTORE Installed Option to Back Up Tools, below.

  • Page 3: Using The Smartpac 2 Usb Disk Backup/Restore Installed Option To Back Up Tools

    Back up your tools on a USB disk using the BACKUP/RESTORE feature on the Initialization Menu. Follow the instructions in Backing Up Tools to a USB Disk in Chapter 4 of your SmartPAC 2 User Manual. After you back up the tool information to the USB disk, proceed with your SmartPAC PRO upgrade.

  • Page 4: Mounting Your Smartpac Pro

    NOTICE TERMINATE BOTH ENDS OF SHIELD Be sure to terminate cable shields at both ends (for example, at SmartPAC PRO Servo and DSI 2). For each shielded cable, perform the following steps. 1. Strip the cable jacket back about 3 inches.
  • Page 5 Upgrading from Original SmartPAC or SmartPAC 2 to SmartPAC PRO 1145200 When you have completed making wiring connections, perform the procedures in Final Checkout in your installation manual. Table 1. Original SmartPAC to SmartPAC PRO Conversion Wiring  Original SmartPAC...
  • Page 6 1145200 Upgrading from Original SmartPAC or SmartPAC 2 to SmartPAC PRO  Original SmartPAC SmartPAC PRO RTS Done Signal Type Connector Connector Pin number  number Position Sensor (if used)  TB107  POS. TB107  GRD. TB107 WPC Port ( Integration only) ...
  • Page 7 Upgrading from Original SmartPAC or SmartPAC 2 to SmartPAC PRO 1145200  Original SmartPAC SmartPAC PRO RTS Done Signal Type Connector Connector Pin number  number AutoSetPAC / WaveFormPAC 2 or 4 Channel (Optional)  GRD. TB102  +RXD2 TB102 ...
  • Page 8 1145200 Upgrading from Original SmartPAC or SmartPAC 2 to SmartPAC PRO  Original SmartPAC SmartPAC PRO RTS Done Signal Type Connector Connector Pin number  number PACNet (Optional)  GRD. TB103  +RXD4 TB103  -RXD4 TB103  TXD4 TB103 ...
  • Page 9 Upgrading from Original SmartPAC or SmartPAC 2 to SmartPAC PRO 1145200  SmartPAC 2 SmartPAC PRO RTS Done Signal Type Connector Connector  number number Resolver Port  TB101  TB101  TB101  TB101  TB101  TB101 ...
  • Page 10 1145200 Upgrading from Original SmartPAC or SmartPAC 2 to SmartPAC PRO  SmartPAC 2 SmartPAC PRO RTS Done Signal Type Connector Connector  number number WPC Adjustment Lockout Switch (Optional)  GRD. TB107  Lockout TB107 Remote Reset (Optional) ...
  • Page 11 Upgrading from Original SmartPAC or SmartPAC 2 to SmartPAC PRO 1145200  SmartPAC 2 SmartPAC PRO RTS Done Signal Type Connector Connector  number number MultiPAC (Special Port - Optional)  +RXD3 TB104  -RXD3 TB104  TXD3 TB104 ...

  • Page 12: Restoring (Copying) Tools To The Smartpac Pro

    PRO that you previously backed up (copied) to a USB disk. 1. Insert the USB disk into the SmartPAC PRO USB connector on the front of the unit. When the “USB disk has been inserted” message appears, press Cancel (Figure 1).
  • Page 13 Upgrading from Original SmartPAC or SmartPAC 2 to SmartPAC PRO 1145200 3. Press Restore SmartPAC 1 or 2 Tools (Figure 3). Figure 3. Backup and Restore Utility: Restore SmartPAC 1 or 2 Tools 4. Press Search for Tool Files (Figure 4). Figure 4. Search for Tool Files...
  • Page 14 5. Press the tool file you want (Figure 5). Figure 5. Select a File Below 6. Tools that are checked will be restored to the SmartPAC PRO. Uncheck any of the tools you do not want restored. Then press Convert to Spro (Figure 6).
  • Page 15 Upgrading from Original SmartPAC or SmartPAC 2 to SmartPAC PRO 1145200 7. The conversion process and restoring of your tools to the SmartPAC PRO takes only a moment to complete. When you see the Conversion completed! message (Figure 7), press Exit. Then navigate to the Tool Manager in Program Menu and verify that the tools have been restored.

  • Page 16: Appendix A - Backing Up Tools Using Smartpac Backup And Restore (Sbr)

    This appendix shows you how to install the SmartPAC Backup and Restore (SBR) utility and use it to back up (copy) up to 200 tools from your original SmartPAC or SmartPAC 2 onto a USB drive. After you install your SmartPAC PRO, copy the tools from the USB drive to the SmartPAC PRO, as described in Restoring (Copying) Tools to the SmartPAC PRO, page 12.

  • Page 17: Installing Sbr On Your Laptop

    Upgrading from Original SmartPAC or SmartPAC 2 to SmartPAC PRO 1145200 Installing SBR on Your Laptop NOTICE YOU MAY NEED ADMINISTRATOR PRIVILEGES TO INSTALL SBR ON SOME SYSTEMS On some Windows operating systems, you may need Administrator privileges to install SBR.

  • Page 18: Connecting Your Laptop To Smartpac

    Failure to comply with these instructions could result in property damage. To establish communications between your laptop and the SmartPAC you wish to back up, you need to connect the computer’s serial port to the communications port on the SmartPAC. The communications port is labelled TB103 on original SmartPAC, TB104 on SmartPAC 2.

  • Page 19: Backing Up Tools

    To connect your laptop to a SmartPAC, using the SBR cable, do the following: 1. With your laptop and SmartPAC both turned off, plug the Phoenix connector at one end of the cable into TB103 on the original SmartPAC board or TB104 on the SmartPAC 2 board. The connector can be inserted in only one orientation.
  • Page 20 7. Click on the SmartPACs tab. 8. Click Add (see Figure A - 5). The Add SmartPAC screen displays (see Figure A - 4), on which you enter identification information about the SmartPAC you are backing up. Information must be entered in all fields.
  • Page 21 "1." Go to your computer’s Device Manager under Ports (COM & LPT) to identify the COM port number. Enter it in the Comm Port field. 11. Enter in the CPU# field a unique number to identify the SmartPAC to the SBR program. The default setting is “1.”...
  • Page 22 14. Click on OK. You are returned to the SBR screen (see Figure A - 6). The information you specified for the SmartPAC you are backing up is displayed on the first line of the screen to the right of an icon representing the SmartPAC control.
  • Page 23 The entry in the Status: field changes momentarily to “Getting Options,” and then to “Getting Tool List,” as the SBR program searches for installed options and tools on the SmartPAC. The results of these searches are displayed in the “Options Discovered:” and “Tools Discovered During Backup:”...
  • Page 24 If the backup is proceeding smoothly, the letter “B” will appear on a turquoise LCD display on the icon for that SmartPAC on the SBR screen, as shown below and in Figure A - 8. When the backup is complete, the message Finished Backup displays in the Status: field on the SBR Backup/Restore screen, and the message Finished displays in the Status: field on the SBR screen.

  • Page 25: Responding To Errors That Interrupt Processing

    Figure A - 9. SBR Backup/Restore Screen, Diagnostics Tab Copy the backed-up tools to a USB drive for later transfer to your SmartPAC PRO, as follows: 1. On your computer, navigate to the Wintriss folder (or where you specified the Tool file to be saved).
  • Page 26 The Diagnostics tab shows the data being transmitted from the SmartPAC to your laptop (during a backup) or from your laptop to the SmartPAC (during a restore) with the date and time recorded for each piece of data. This information is displayed in the “Serial Activity Log” window.

  • Page 27: Responding To A Checksum Error

    SmartPAC on the SBR screen, as shown below, A “checksum” is a calculated number used to verify that the tool data being loaded at the SmartPAC is identical to the settings programmed for the tool. SmartPAC calculates the checksum whenever a tool number is programmed or tool settings are changed;...
  • Page 28 For each tool that generates a checksum error, do the following: 1. In SmartPAC Program mode, select a tool to edit on the Tool Program Menu. 2. Select each of the Tool Program Menu items (i.e., COUNTERS, DIE PROTECTION, CAM SWITCH, etc.) and check the settings, correcting any parameters that have been corrupted.
