Chapter 4 Starting and Configuring Router
4
4.1

Starting Router

4.1.1 Set ting Up the Configuration
Environment
When you use the router for the very first time, you will need to configure the router through
a console port as follows:
Step 1
Step 2
When you have finished
router.
4.1.2

Powering on Router

4.1.2.1 Check before Power-on
Before powering on the router, please check
if the power cable and the grounding cable are connected correctly.
if the power supply voltage meets the requirement.
Whether the cable connection is correct and the PC or terminal for configuration has
been starte
4-4
St arting and Configuring Router
As shown in the following diagram, connect the serial port of a character
terminal or PC to the Console p
cable.
Set up the local configuration environment through the Cons
Configure the communication setting parameters of the terminal. If a PC is
used, you must run the terminal simulation program, for example, Windows
HyperTerminal. The
HyperTerminal as example. Run the HyperTerminal software to set up a new
connection. Select the serial port to be connected with the Console port of the
router. Set the communication parameters: 9600 for baud rate, 8 data bits, 1
stop bit, no parity check, and no flow control. In addition, select VT100 as the
simu lation terminal type.
building the configuration environment, you may power on the
d and set up.
ort of the router through the standard RS232
following describes
Installation Manual
ole port.
the procedure with the
