Fastening Router; Mounting In The Cabinet; Mounting On The Workbench - Ruijie RSR10-01G Hardware Installation Manual

Chapter 3 Installing Router
3.2 Fast eni g Router n
The process to mount the router to the specified location is to fasten it. At the end of the
installation preparation, you need to fasten the router to the specified location. Routers are
usually mounted in or on:

Mounting in the Cabinet

Mounting on the Workbench

3.2.1 Mounting in the Cabinet
RSR10-01G can be mounting in the cabinet though the aluminium alloy slot and fixing
accessories( the fixing accessories should be purchased separately) , as shown in the
following figure.
Hanger:
3.2.2 Mounti ng on the Workbench
In real environment, more often the router is placed on a clean workbench. This case is easy
as long as you pay attention to the fo
Ensure that th
The supplied plastic cushion is stuck to the small hole at the bottom of the router and a
room of 10cm is set aside around the router for dissip
No weight is placed on the top of the route
3-2
llowing:
e workbench is stable and is properly grounded.
ation.
r.
Installation Manual
