Instruction Manual
INSTALLING THE AILERONs LINKAGES
3x25mm
Cut off shaded portion
Assemble left and right
sides the same way
Aluminum ball
Aileron
< Bottom view >
3mm
3mm
3x12mm
4
TIGER MOTH
3 x 12mm Screw
4
3mm
Nut
2
3mm
Nylon Nut
2
3mm Washer
2
Aluminum ball
4
4
2
2
3 x 25mm Cap Screw
2
80mm Push rod
2
3x12mm
Apply threadlocker
(screw cement).
