SMC Networks ITV1000 series Operation Manual page 6

Wiring diagram（Monitor output）
When the monitor output is not being used, prevent it from touching the other
wires as this can cause a malfunction.
Analogue output・Voltage type
（ITV※0※※-※1）
○
-
Monitor output voltage
○
+
Only use equipment with a minimum load
impedance of 100kΩ.
Switch output・NPN type
（ITV※0※※-※2）
Load
When a current of approx.150mADC or
more is applied, the over current
circuit is archived,
displayed and the operation stops.
Please use with installing the load
that the output current becomes to
80mADC or less.
△
CAUTION
！
Analogue output・Current (sink) type
１：
Brown
３：
Blue
２：
White
４：
Black
Only use equipment with a maximum load
impedance of 250Ω.
１：
Brown
３：
Blue
２： White
４：
Black
When a current of approx. 150mADC or
more is applied, the over current
Er.5 is circuit
displayed and the operation stops.
Please use with installing the load that
the output current becomes to 80mADC or
less.
―6―
（ITV※0※※-※4）
○
+
Monitor output current
○
-
Switch・PNP type
（ITV※0※※-※3）
Load
is archived,
１：
Brown
３：
Blue
２：
White
４ ：
Black
１：
Brown
３：
Blue
２：
White
４：
Black
Er.5 is
