Physical Specifications – Pallet

Pallet Specifications

Table 7 Pallet Dimensions –
Module Only
Height
87 in.
221.0 cm
Physical Specifications – Library
Scalar i6000 Planning Guide
The library control modules, expansion modules, and parking modules
are each shipped on the same type of specially designed pallet. For dual-
robot new installs or upgrades, the robots will be shipped inside the
module.
The pallet's dimensions are listed in
Width
42.5 in.
108.0 cm
This section contains the physical specifications for all possible library
configurations.
The maximum weight, distributed load, and point load figures provided
in the sections below were calculated using the heaviest configurations
for a given frame count. Where differences between Gen 1/Gen 2 or
single robotics/dual robotics exist, the heaviest number was used.
Note: If the library is installed on a raised floor, the raised floor should
be stabilized to prevent any horizontal movement. The library
has four point loads each on the control and expansion
modules.
This section covers:
• Configuration Rules
Chapter 3: System Specifications
Table 7.
Length
48 in.
121.9 cm
on page 58
Physical Specifications – Pallet
57
