Figure 9 Dual Robotics Library
- No HDEM
Left parking
(Position 0)
(left-most two columns)
Scalar i6000 Planning Guide
Side panels, doors, and door posts have been removed for clarity.
Control
module module
(Position 1)
Left parking space
Dual-Robot Configurations and Parking Modules
Right parking
Expansion
module
module
(Position 3)
(Position 2)
Chapter 2: Description
Right parking space
(right-most two columns)
19
