Figure 2 Front and Back View
of the Control Module
Magazines
and
cartridge
slots
Scalar i6000 Planning Guide
front view
Robot (Gen 1)
Note: A control module can only contain a 24-slot I/E station.
rear view
24-slot
I/E station
Drive
clusters
Chapter 2: Description
Control Module
I/O
management
unit
Library
management
module
Power
supplies
9
