Chapter 2: Description

Aisle Lights

Aisle Lights

Webcam

38
Aisle lights are used to illuminate the inside of a module and can be
used in conjunction with a webcam to monitor activity within the
library. Aisle lights can be configured to turn on at various time intervals
and for specific durations. If a webcam is installed, the aisle lights will
turn on automatically when the webcam is accessed and turn off when
stopped.
Note: Aisle lights are available for i2000/i6000 libraries. However, not
all i2000's have the necessary hardware features. The Control
Module serial number in your i2000/i6000 library configuration
must be at least 203102253 or begin with 263.
Note: For the aisle lights to automatically come on when the webcam
is accessed, the minimum library firmware code is i10.2
(640Q.GS08801).
A webcam is an optional component that can be installed to any
expansion module within a library. In conjunction with aisle lights, a
webcam is used to monitor activity within the library.
Requirements for installing a webcam include:
• External 110v power source
• Cable from external Ethernet port to webcam interface module
• Aisle lights
• Scalar i6000, Gen2, version 10.2 or higher
• Fire Suppression port not already in use
