UM2124
4
X-CUBE-SPN7 and X-CUBE-SPN8 software
expansion for STM32Cube
4.1
Firmware package architecture overview
The firmware example in X-CUBE-SPN7 and X-CUBE-SPN8 is provided for three different
IDE tools, IAR EWARM, Keil MDK-ARM, AC6 Workbench. In this case the IAR IDE
workspace appears as shown in the following figure.
The firmware solution is built around three independent levels that can easily interact with
each other as described in
17: "X-CUBE-SPN8 software
X-CUBE-SPN7 and X-CUBE-SPN8 software
Figure 15: Project workspace on IAR IDE
Figure 16: "X-CUBE-SPN7 software architecture"
architecture".
DocID029868 Rev 1
expansion for STM32Cube
and
Figure
19/39
