ATCOM AT800 series User Manual page 11

AT800 AT800 AT800 AT800 Series
Description of the keys and Screen:
Soft buttons
LCD Screen
Navigation button
1~9,*#
Programmable Key
Menu
Mute button
Headset button
MWI
Login button
ATCOM TECHNOLOGY CO., LIMITED
Downloaded from www.Manualslib.com
Series Series User Series User User User Manual Manual Manual Manual
Press to select an feature shown in the soft button features
Display screen for the phone: It shows the date, time, phone number,
incoming caller's ID(if available),line/call status, extension numbers and
the soft button features.
1. Move cursor up and down when pressed in menu reviewing.
2. Adjust output volume when pressed in talking state
3. Adjust ringer volume when pressed in idle state.
For entering numbers, letters or characters
Function key can be defined as Speed dial key, CFWD, Hold, Xfer, ConF,
DND, Redial, Voicemail.
Enter Keypad menu settings
Mute/un-mute mic-phone in talking state
Pick up phone to make outgoing calls or answer incoming calls.
Message waiting indicator/ Ringing indicator
1. Press to enter login interface to input SIP account username and
password to register to sip server.
2. Press in login-ed state to input SIP account password to logout.
manuals search engine
(AT800/AT800P)
