Rcom PRO 20 User Manual page 35

RCOM Manager File
Select "RCOM_Manager" file above Window explorer.
6
Double-click "RCOM_Manager" file.
7
The file as above will show.
8
Click "File".
(Be sure to check the incubator is (Be sure to check the incubator is
(Be sure to check the incubator is (Be sure to check the incubator is
connected with PC through USB cable.) connected with PC through USB cable.)
connected with PC through USB cable.) connected with PC through USB cable.)
Select firmware file with "BIN" extension.
9
(The name can be different from the version.)
Click
Click
Click
Select Firmware file and click "Update(U)" button.
10
Wait a while during updating is on process.
11
New version Incubator (about 9min. is needed)
Old version Incubator (about 19min. is needed)
The message shows,
12
it means update is normally completed.
Then, it returns to initial condition.
When it failed, error message will show.
In this case, restart from first stage.
For normal operation, unplug the power
13
cord and re-plug again after firmware
upgrade completed.
Click
