7 ) Explanation Of Each Part - Rcom PRO 20 User Manual

1
Fundamental Terms of each part On the Main Screen
1
4
RCOM Logo Button : Basic conditions setting and testing. (Refer to the page 17.)
1
2 Status : Real-time display of incubator Temp. humidity, egg-turning intervals & angle, D-Day, and others
conditions.
Setting : Selecting the species of birds, Temp. mode (Standard mode or Special mode), Egg size,
3
Working Mode (Automatic, Manual, or PC connecting). You also can setup temp. humidity,
incubation period, egg-turning intervals and angle by using setting bar.
4
For selecting specified Egg for input each egg's data.
Selecting Incubation start or termination, egg-turning angle, Database, and Graph.
5
6
Input project related data. ( Project Name, Bird Name, Bird Species etc.)
Input each egg's data which is selected at 4. (laid date, length of egg, and width of egg etc.)
7
8
Among every egg, input selected egg's weight changes everyday during incubation period.
9 With weight change data which you input at 8, it indicates daily weight loss graph and density
loss graph.
.
7. Explanation of Each Part
6
2
5
9
3
8
7
