Rcom PRO 20 User Manual page 13

If the computer didn't connect with incubator
5
automatically, you need to connect manually.
For manual connection, input password at the top.
Password is made of compounding of the date and
minute.
Refer to the example below, and input password.
Then, logo setup window will be unlocked, and
you can manually set up.
Ex1) May. 28 11 : 19
Ex2) July. 9 10 : 08
After input the password, click "Pass Word"
button.
T I P!
When you input password, be sure to refer
the time of PC timekeeper.
If you don't refer PC timekeeper,
the password input can fail.
Click
2819
0908
Refer
6
For connecting communication manually,
1
press Com1~ Com 10 button in order
at 5sec. intervals.
On the communication linkage, (
2
will appear. When this icon comes out,
do not select other Com.
Incubator normally connected.
If you close the window, all connection will
3
be completed.
Click
3
확인 확인 확인 확인
2
Click
1
) icon
12 12 12 12
