To adjust the mobile sensor position according to the notch position on paper, proceed as follows:
for B202H
1
Lift the palstic cover.
2
Adjust the paper width
(see previous paragraphs).
3
ATTENTION:
Do not touch the head heating line with bare hands or
metal objects.
Do not perform any operation inside the printer immedi-
ately after printing because the head and motor tend to
become very hot.
Open the printer cover
to the vertical up position.
User manual
4. OPERATION
KPM150H-AERO 41
