SmartNode 4400 Getting Started Guide

Voice connectivity - FXS

2-wire Loopstart, RJ-11/12
Short haul loop 1.1 km @3REN
EuroPOTS (ETSI EG201 188)
Programmable AC impedance, feeding, and ring voltage; on-hook voltage 48 VDC
Caller-ID Type-1/2 FSK and ITU V.23/Bell 202 generation

Ethernet interface

The SN4400 series has dual 10/100-Mbps Ethernet ports presented on two RJ-45 connectors supporting:
• 100Base-TX half-/full-duplex operation
• 10Base-TX half-/full-duplex operation
• Auto detection and fallback

Console port

The RS-232 port provides for initial configuration of the Model SN4400 series. The RS-232 port supports:
• Asynchronous data rate of 9600 bps, 2 bits, no parity, 1 stop bit, no flow control
• An RJ-45 connector with EIA-561 (RS-232) pinouts
• A management interface (such as HyperTerminal) that supports VT-100 terminals

FXS ports

The FXS ports provide for connection of up to 32 analog FXS devices on a 50- or 64-pin RJ-21X connector
located on the rear panel.

PPP and Frame-Relay support

• Frame-Relay (8 PVCs)
• RFC1440, FRF.12 fragmentation
• LMI, Q.933D, ANSI 617D, Gang of Four (an encapsulation method created by the four companies: Cisco,
Northern Telecom, StrataCom, and DEC which differs from the IETF encapsulation)
• PPP, PAP, CHAP, LCP, IPCP

Voice processing (signaling dependent)

Voice codecs:
• G.711 A-Law/ -Law (64 kbps)
• G.726 (ADPCM 40, 32, 24, 16 kpbs)
• G.723.1 (5.3 or 6.3 kbps)

Voice connectivity - FXS
