SmartNode 4400 Getting Started Guide
Identification of the SmartNode devices via SNMP
All SmartNode devices have assigned sysObjectID (.iso.org.dod.internet.mgmt.mib-2.system.sysObjectID)
numbers (see
table
9).
SmartNode Model
SN4408/JS/RUI
SN4412/JS/RUI
SN4416/JS/RUI
SN4424/JS/RUI
SN4432/JS/RUI
According to
table
9, an SNMP get request to .iso.org.dod.internet.mgmt.mib-2.system.sysObjectID of a Smart-
Node 4412-JS device reads out a numeric OID of 1.3.6.1.4.1.1768.2.4.12.2, which represents a SmartNode
4412 device. The mapping of the sysObjectID to each of the SmartNode model is realized with the Smart-
Node product identification MIB.
IMPORTANT
Identification of the SmartNode devices via SNMP
Table 9. SmartNode Models and their Unique sysObjectID
SysObjectID
1.3.6.1.4.1.1768.2.4.12.1
1.3.6.1.4.1.1768.2.4.12.2
1.3.6.1.4.1.1768.2.4.12.3
1.3.6.1.4.1.1768.2.4.12.4
1.3.6.1.4.1.1768.2.4.12.5
The SNMP agent running in SmartWare is SNMP version 1
(SNMPv1) compliant. SNMP version 2 (SNMPv2) and SNMP
version 3 (SNMPv3) are not currently supported.
B • Specifications
54
