SmartNode 4400 Series Getting Started Guide
3. Loading the configuration (see
work" on page 39 for details.
1. Download configuration example from the CD-ROM
included with your SmartNode device or from the
Patton Web server at www.patton.com/voip
3. Load configuration onto the SmartNode
2. Modify the configuration as needed
Note
Note

1. Configure IP address

Factory-default IP settings

Both Ethernet interfaces are activated upon power-up. The LAN interface ETH 0/1 (LAN) provides a default
DHCP server. The factory default configuration for the Ethernet interface IP addresses and network masks are
listed in table 7. Both Ethernet interfaces are activated upon power-up. LAN interface ETH 0/1 (LAN) pro-
vides a default DHCP server.
Table 7. Factory default IP address and network mask configuration
WAN interface Ethernet 0 (ETH 0/0)
LAN interface Ethernet 1 (ETH 0/1)
DHCP IP address range
If these addresses match with those of your network, go to section
work" on page 39. Otherwise, refer to the following sections to change the addresses and network masks.

1. Configure IP address

figure 16). Refer to section
Figure 16. Loading the configuration
You can manually configure the SmartNode. You do not have to load
a configuration file.
The SmartNode CD-ROM contains a collection of third party soft-
ware tools (including TFTP servers and Telnet utilities) to help you
configure, operate and monitor the SmartNode device.
192.168.1.10 - 192.168.1.19
4 • Getting started with the SmartNode 4400 Series
"2. Connecting the SmartNode to the net-
LAN
LAN (ETH 0/1)
IP Address
DHCP
192.168.1.1
"2. Connecting the SmartNode to the net-
rt s
P o
lc o
T e
5 0
o le
n s
C o
s e t
R e
0 /0
H
E T
0 /1
H
E T
WAN
(ETH 0/0)
Internet or
WAN (optional)
Network Mask
DHCP
255.255.255.0(/24)
255.255.255.0(/24)
