SmartNode 5200 Getting Started Guide 3 • SmartNode installation
Power
LAN ports WAN
1–4 activity
Figure 5. Router front panel LEDs
4. Verify that the green Power LED is lit (see figure 5).
Congratulations, you have finished installing the SmartNode Gateway Router! Now go to chapter 4, "Initial
configuration" on page 25.
Installing the gateway router 24
