Symbol Display
Overview
EN-40 Original User Guide | Pedelec Impulse Evo Version 1
Meaning
As a roadbook: List of places on the
route. The list is read from the top
down.
As an overview: Display of route
title, length (in km) and journey
time (in h).
4.5 Impulse Evo Smart display: Charging the
smartphone
You can use the USB charge socket on the display
to charge your smartphone battery.
WARNING
Safely secure the smartphone and its charger cable whilst the cycle is
moving. They may otherwise get caught up in rotating parts, causing a
serious fall. Ask your cycle dealer for a suitable smartphone holder.
Requirements:
Cable type
USB OTG (on the go) micro cable
1. Use the correct cable to connect the smartphone to the display
USB power jack
