Configuring Settings In The Menu; Go To The Main Menu; Navigating Within A Menu; Returning To The Next-Highest Menu Level - Derby cycle Pedelec Impulse Evo User Manual

6. Select "SET favourites" using the / buttons. The option selected is
shown with a black background.
7. Confirm with the
button. You access the SET favourites.
8. Select the required option using the / buttons. It has a black
background.
9. Briefly press the button to set or remove the option in the box
10. Once you have made the selection required, you can return to the
menu sub-items with "Back"
3.4 Menu
3.4.1

Configuring settings in the menu

3.4.1.1 Go to the main menu

1. When you are in the start menu, press the
access the main menu.
ECO
140 km 00:02
0
.0
km/h
Trip time Trip
00.00.00 0.00 km
Start menu
140 km 00:02 POWER
0
.0
km/h
Trip time Trip
00.00.00 0.00 km
EN-22 Original User Guide | Pedelec Impulse Evo Version 1
button for 3 seconds. You
Main menu
Drive data
Delete trip data
Delete tour data
Settings
Back
Main menu

3.4.1.2 Navigating within a menu

1. Navigate to the required place using the / buttons.
The option selected is shown with a black background.
2. Confirm your selection by briefly pressing the
You access the next-lowest menu level.

3.4.1.3 Returning to the next-highest menu level

There are two ways to return from a menu to the next-highest menu level:
a) Back option
1. Navigate to the Back option using the / buttons. It has a black
background when selected.
2. Confirm with the
button. You return to the next-highest level.
b) Brief pressing of the button
1. If there is no Back option, and one of the options displayed is selected,
briefly press the button to return to the next-highest level

3.4.1.4 Returning to the start menu

1. Pressing the button for 3 seconds returns you to the start menu
button.
