Page 1: Installation Guide
SwitchX 36 Port QSFP Ethernet Switch Installation Guide P/N:MSX1035B-1BRR, MSX1035B-1SFR, MSX1036B-1BRR, MSX1036B-1SFR Rev 1.4 www.mellanox.com... - Page 2 SwitchX®, Virtual Protocol Interconnect® and Voltaire® are registered trademarks of Mellanox Technologies, Ltd. Connect-IB™, FabricIT™, MLNX-OS™, ScalableHPC™, Unbreakable-Link™, UFM™ and Unified Fabric Manager™ are trademarks of Mellanox Technologies, Ltd. All other trademarks are property of their respective owners. Mellanox Technologies...
-
Page 3: Table Of Contents
Chapter 3 Connecting to the Switch Platform 3.1 Starting an SSH Connection to the Switch (CLI) 3.2 Resetting the Switch Appendix A Transferring the Power Cord Appendix B QSFP Interface Appendix C RJ45 Console and Ethernet Interfaces Appendix D Replacement Parts Ordering Numbers Mellanox Technologies... -
Page 4: List Of Figures
Status LEDs 5 Minutes After Power On Figure 8: Two Power Inlets - Electric Caution Notifications Figure 9: Console Port Figure 10: Reset Button Figure 11: Transfer Power Cord Figure 12: Install the Switch Slide Figure 13: Transfer Power Cord Finished Mellanox Technologies... -
Page 5: Revision History
Converted Visio graphics to Mechanical drawings Added figure 2. January 2012 Added SX1016 Switches January 2012 Fixed wizards, Added IPv6 August, 2011 Added one OPN Added QSG to the parts list Added China RoHS to the parts list July, 2011 Initial release Mellanox Technologies... -
Page 6: About This Manual
Mellanox MLNX-OS SwitchX Software This document contains information regarding configuring User Manual and managing Mellanox Technologies’ SwitchX Switch Platforms. MLNX-OS Software Command Reference Guide Command Reference Guide for MLNX-OS listing all of the commands available through MLNX-OS with explanations and examples. -
Page 7: Mellanox Part Numbering Legend
BEWARE! This symbol indicates a situation that can potentially cause personal injury or damage to hardware or software. Mellanox Part Numbering Legend Mellanox Part Numbering Legend Place Field Decoder Mellanox Technologies System Type SwitchX Switch Protocol 10 = Ethernet Port and 35 = 36 ports with Fabric Management Management... -
Page 8: Chapter 1 Installing The Switch In The Rack
See “Mellanox Part Numbering Legend” on page 7 for explanation of the switch depth according to the Model numbers. Table 3 - Installation Kit According to Rack Size Kit OPN Rack Size MSX60-BKIT 40-60 cm MSX60-SKIT 60-80 cm Mellanox Technologies... -
Page 9: Mechanical Installation
=>Support => Customer Support Portal Login 1.3.1 Installing the Switch in the Rack Tools and Customer Supplied Parts: • Phillips Screwdrivers #1 and #2 • Grounding screw • ESD strap • Grounding wire sufficient to reach a valid ground. • ESD mat Mellanox Technologies... -
Page 10: Figure 1: Rack Rail Kit Parts
Choose which side of the switch you want even with the rack vertical support. Either the side with the power supply units or the side with the QSFP connectors can be even with one of the vertical rack supports. Mellanox Technologies... -
Page 11: Figure 2: Placement Of Switch In Rack
See Figure 3,“Mounting Options”. Will the connector side be recessed past other equipment in the rack and will this be prob- lematic? The installation kit allows for a 2” recess of the switch past the vertical support. Mellanox Technologies... -
Page 12: Figure 3: Mounting Options
Figure 4: Screwing on the Rail 5 screws per side are needed for the short switch 7 screws per side are needed for the standard switch There are 16 screws in the kit; you will have left over screws. Mellanox Technologies... -
Page 13: Figure 5: Inserting The Caged Nuts
Figure 6: Slide the Rail into the Rail Slide This side of the rail kit goes on the side of the rack you will slide the switch into. This is the same side of the switch that will be next to the vertical support. Mellanox Technologies... -
Page 14: Grounding The Switch
If so, connect a ground wire to one of the casing screws and connect the other end to a valid ground. If you choose to not use the ground screw, make sure that the rack is properly Mellanox Technologies... -
Page 15: Power Connections And Initial Power On
Caution: When turning off the switch, make sure ALL Connector LEDS are off to ensure a powered down status. Mellanox Technologies... -
Page 16: Figure 8: Two Power Inlets - Electric Caution Notifications
Pour isoler com- sind die Netzstecker aller of the switch platform. pletement le module en cause, Il Netzteile zu entfernen faut de’brancher toutes les alimen- tations stabilise’es. Mellanox Technologies... -
Page 17: Chapter 2 Configuring The Switch
Configure a serial terminal program (for example, HyperTerminal, minicom, or Tera Term) on Step 2. your host PC with the settings described in Table 4 Table 4 - Serial Terminal Program Configuration Parameter Setting Baud Rate 9600 Data bits Stop bits Parity None Mellanox Technologies... - Page 18 Step 3: Enable IPv6? [yes] yes The management interface will be able to use IPv6 addresses. Step 4: Enable IPv6 autoconfig (SLAAC) on mgmt0 This turns on autoconfiguration of the IPv6 addresses. interface? [no] no This is unsuitable for DHCPv6. Mellanox Technologies...
- Page 19 Config mode. Otherwise hit <enter> to save changes and exit. Choice: <Enter> Configuration changes saved. To return to the wizard from the CLI, enter the “con- figuration jump-start” command from configuration mode. Launching CLI... <switch name> [> Mellanox Technologies...
- Page 20 To change an answer, enter the step number to return to. Otherwise hit <enter> to save changes and exit. Choice: Configuration changes saved. To return to the wizard from the CLI, enter the "configuration jump-start" command from configure mode. Launching CLI... switch-1 > Mellanox Technologies...
- Page 21 Before attempting a remote (for example, SSH) connection to the switch, check the mgmt0 Step 5. interface configuration. Specifically, verify the existence of an IP address. To check the current mgmt0 configuration, enter the following commands: sx-43 [standalone: master] > enable sx-43 [standalone: master] # show interfaces mgmt0 Mellanox Technologies...
-
Page 22: Rerunning The Wizard
TX carrier: RX frame: TX collisions: TX queue len: 1000 Rerunning the Wizard If you want to rerun the wizard run the following commands: sx-43 [standalone: master] > enable sx-43 [standalone: master]# configure terminal sx-43 [standalone: master]# configuration jump-start Mellanox Technologies... -
Page 23: Chapter 3 Connecting To The Switch Platform
On the connector side panel under the system LEDs is a reset button. This reset button requires a tool to be pressed. DO NOT use a sharp pointed object such as needle or push pin for pressing the Reset button. Sharp objects can cause damage, use a flat object to press this reset button. Mellanox Technologies... -
Page 24: Figure 10: Reset Button
You will then be able to enter without a pass- word and make a new password for the user admin. The SwitchX Series User Manuals can be found at: http://www.mellanox.com Mellanox Technologies... -
Page 25: Appendix A Transferring The Power Cord
Make sure that you place the cord so that the correct end of the cord will be at the power side of the switch. This will depend on which of the four mounting options you choose. Figure 11: Transfer Power Cord Put the power cord in the switch slide channel. Screw the switch slides to the switch. Mellanox Technologies... -
Page 26: Figure 12: Install The Switch Slide
Rev 1.4 Connecting to the Switch Platform Figure 12: Install the Switch Slide Figure 13: Transfer Power Cord Finished Return to step 4 on page 12 and continue the installation. Mellanox Technologies... -
Page 27: Appendix B Qsfp Interface
+3.3 V Power supply transmitter Vcc 1 +3.3 V Power Supply LPMode Low Power Mode Ground Tx3p Transmitter Non-Inverted Data Input Tx3n Transmitter Inverted Data Input Ground Tx1p Transmitter Non-Inverted Data Input Tx1n Transmitter Inverted Data Input Ground Mellanox Technologies... - Page 28 Rev 1.4 Connecting to the Switch Platform 18.35 View into Rear of Connector 8.50 18.35 View into Front of Cage 8.50 Mellanox Technologies...
-
Page 29: Appendix C Rj45 Console And Ethernet Interfaces
R J 4 5 _ R X D G N D G N D RXD+ RJ45_TXD G N D P in 8 L o o k in g in to th e S o c k e t Bl/W RXD- RJ45_RXD Br/w Mellanox Technologies... -
Page 30: Appendix D Replacement Parts Ordering Numbers
Power cord Type B for Japan, ACC000212 Power cord Type I for Australia ACC000213 Installation Kit for short switches in racks 40-60 cm deep MSX60-BKIT Installation Kit for short or standard switches in racks 60-80 cm deep MSX60-SKIT Mellanox Technologies...
