3. The module can now be placed in the lower opening. Put the side strips back on
each side of the module and fasten them in place with their screws.
Important! The Cerebrum Module only fits in the upper opening of the
Maxxyz Module Frame.
4. Connect the Power interconnect cable to the MAINS IN connector, or, if only one
module is used, connect the IEC Power cable (part number 11501012) to the
MAINS IN connector.
Maxxyz Modules User Manual
8
