................................................................ EtherCon connectors in housing)
EtherDMX data ................................................... Neutrik RJ-45 socket (accepts Neutrik
................................................................ EtherCon connectors in housing)
DMX data..............................................................................................5-pin locking XLR
USB devices .......................................................................................... USB host socket
Microphone.................................................................................... 6.3 mm mono socket
Audio in/out.................................................................................................... RCA phono
VGA ................................................................................................. 15-pin D-sub female
Other modules (not Cerebrum)
AC Power input....................................................................................I.E.C. male socket
AC Power output ..............................................................................I.E.C. female socket
LINK USB data output ........................................ Neutrik RJ-45 socket (accepts Neutrik
................................................................ EtherCon connectors in housing)
LINK USB data input ........................................... Neutrik RJ-45 socket (accepts Neutrik
................................................................ EtherCon connectors in housing)
DMX data..............................................................................................5-pin locking XLR
USB devices .......................................................................................... USB host socket
USB input ...........................................................................................USB device socket
LAMP output......................................................................... 2.5 mm DC bayonet socket
....................................... (also accepts 2.5 mm DC plugs without bayonet)
Electrical (all modules)
AC power........................................................................... 100-240 V nominal, 50/60 Hz
Power supply unit ........................................................................Full range switch-mode
Main fuses ......................................................................................................... 2 AT (x2)
AC power throughput.......................................................unswitched, unfused, Max. 6 A
Lamp output (not on Cerebrum) ..................................................................... 12 V PWM
Functional
Cerebrum Module
Grand master fader and button
Flash master fader and button
16 x view buttons, 2 x view scroll buttons
Digital encoder wheels for window scrolling and screen/desk lamp intensity
Protocol: DMX512, Artnet (ACN and RDM pending)
2 DMX universes, expandable to 32
1024 channels, expandable to 16384
No limit to number of DMX channels per fixture
Extensive fixture library for all known manufacturers
65000 presets for each group of functions (P/T, color, gobo, etc.)
Effect generator for automated programming of complex effects
Customizable highlight and lowlight function to identify individual fixtures
Relative or absolute programming
Maxxyz Modules User Manual
19
