• Before transportation, secure modules in place in a frame with the supplied
screws.

1.3 Connecting to power

Maxxyz Modules automatically adapt to AC mains power at 100-240 V nominal,
50/60 Hz. Do not connect them to power outside this range.
You may need to install a cord cap that fits your supply on the power cable. A 3-
prong grounding-type plug must be installed following the plug manufacturer's
instructions. The table below shows some possible pin identification schemes; if the
pins are not clearly identified, or if you have any doubts about proper installation,
consult a qualified electrician.
Wire color (standard EU code)
brown
blue
yellow/green

1.4 Included items

Each Maxxyz Module, part numbers 90732140 (Cerebrum), 90732150
(Programmer), 90732160 (Button), 90732170 (Submaster) and 90732180
(Playback), contains the following items:
• Maxxyz Module
• Two 2 AT fuses, installed
• IEC Power cable (part number 11501012)
• Ethercon Network cable (part number 11840144)
• USB cable (part number 11840066)
• User manual (part number 35000223)
Each Module Frame, part number 90732120 (shipped in flightcase) and 90732130
(shipped in cardboard box) contains the following items:
• Module Frame with attached Ethercon Power interconnect cables and
desklight cable
• Desk lamp (built in)
• Blind cover plate (installed)
• Dust cover
Maxxyz Modules User Manual
Pin Symbol
live L
neutral N
ground
