Adjustment of Swing

Notes:
Up &down swing can be selected to control start or stop
●
of up & down swing motor by pressing up & down button on
remote controller or FUNC button on displayer,so that guide
louver will swing up and down or stop at a certain angle.
If indoor fan has operated,press up &down button on remote
●
controller. Refer to remote controller instruction for swing
mode.
Select up &down swing button on displayer to set it,and
●
then press
▼or ▲
it once to start and repress it to stop.
● If stop of swing is selected,the characters and icon about
up & down swing will disappear.When other states are selected,
characters and icon about up & down swing will show again.
Front or upward air supply should be set for cooling and
●
dehumidifying mode.(Fig.4)
At the begining of startup of the unit,downward air supply
can be selected for quick cooling around the people,but
it can not be kept for a long time in order to ensure good
circulation of air in the room .
● Downward air supply should be set for heating.(Fig.5)
Up & Down Swing
button to start or stop swing.Press
Guide louver (upward)
Guide louver (downward)
18
Guide louver (level)
or can be set
Fig.4
Fig.5
or can be set
