Operation of Remote Controller

Note: Be sure that there are no obstructions between receiver and remote controller; Don't drop
or throw the remote control; Don't let any liquid in the remote control and put the remote control
directly under the sunlight or any place where is very hot.
Signal transmitter
Remote controller
X-FAN
TURBO
ON/OFF
ON/OFF button
Press this button to start or stop the unit.It will
●
clear timer or sleeping function of last time.
MODE
Mode button
Press this button, the running mode will change
●
as below:
AUTO
COOL
DRY
FAN
HEAT (Note:no for coolling
Names and functions of remote control buttons
FAN
AUTO
HEALTH
AIR X-FAN
HUMIDITY
FILTER
TURBO
HOUR
ON/OFF
ON/OFF
MODE
FAN
TEMP
TIMER
LIGHT
SLEEP
only unit)
(＋/－)
T E M . P
Pressing +button , the setting temp will be
●
increased by 1 .Pressing -button,the
℃
setting temp. will be decreased by 1
The temp. will be changed quickly
the button continuously .Setting temp. range
is 16~30 ℃。
FAN
FAN speed button
Press this button once,then fan speed will
●
change as below:
Auto
Low speed
High speed
Note:Under the Dry mode, the fan speed isn't
adjustable, low fan speed is imperative,
but when operating this button, the wireless
remote control will send this signal.
Swing up and down button
Simpleness swing mode is defaulted for wireless
●
remote control, in this mode, press this button,
could turn on or turn off the Up and down
swing function.
●
When unit is turned off, synchronously press
"+" and Up and down swing buttons, it could
be switched between the simpleness swing
mode and stationary swing mode, at this time,
blinks 2 seconds.
● In Stationary swing mode, press this button,the
angle for Up and down swing as show in below:
When up and down swing louver is working,
●
when turn off the unit, the siwng louver will
immediately stop at current position.
shows up and down swing louver swings back
and forth as show in the above figure.
12
(＋/－)
button
℃
by pressing
Middle speed
