Endress+Hauser Proline Promass 80A Technical Information page 33

Coriolis mass flow measuring system the single-tube system for highly accurate measurement of very small flows
Hide thumbs Also See for Proline Promass 80A:
Table of Contents

Advertisement

Proline Promass 80A, 83A
Endress+Hauser
4-VCO-4-connection with mounting kit: ¼" NPT-F
Mounting kit ¼" NPT-F connection: 1.4539/904L, Alloy C-22
DN
L
1/24"
14.4
1/12"
14.9
1)
1/12"
14.9
1/8"
22.4
1)
1/8"
22.4
1)
High-pressure version only available as 1.4539/904L; All dimensions in [inch]
4-VCO-4-connection with mouting kit: 1/8" or ¼" SWAGELOK
Mounting kit SWAGELOK connection: 1.4539/904L
DN
L
1/24"
14.2
1/24"
14.6
1/12"
17.4
1/12"
17.4
1)
1/12"
17.4
1)
1/12
17.4
1/8"
22.4
1)
1/8"
22.4
1)
High-pressure version; All diemnsions in [inch]
Esc
-
+
E
+1.5
(+0.06)
L
–2.0
(–0.08)
P
Q
AF 3/4"
1/4" NPT
AF 3/4"
1/4" NPT
AF 3/4"
1/4" NPT
AF 3/4"
1/4" NPT
AF 3/4"
1/4" NPT
Esc
-
+
E
+1.5
(+0.06)
L
–2.0
(–0.08)
P
Q
AF 7/16"
1/8"
AF 9/16"
1/4"
AF 7/16"
1/8"
AF 9/16"
1/4"
AF 7/16"
1/8"
AF 9/16"
1/4"
AF 9/16"
1/4"
AF 9/16"
1/4"
mm (inch)
a0003185-en
di
0.04
0.07
0.06
0.14
0.12
mm (inch)
a0003186-en
di
0.04
0.04
0.07
0.07
0.06
0.06
0.14
0.12
33
