Transmitter remote version, wall-mount housing (non hazardous area and II3G/zone 2)
Esc
-
A
H
Dimensions in SI units
A B C
215 250 90.5
L M N
95 53 102
1)
Fixing bolt for wall assembly: M6 (screw head max. 10.5 mm)
All dimensions in [mm]
Dimensions in US units
A B C
8.46 9.84 3.56
L M N
3.74 2.08 4.01
1)
Fixing bolt for wall assembly: M6 (screw head max. 0.41 inch)
All dimensions in [inch]
+ E
S
R
T
P
D E F
159.5 135 90
O P Q
81.5 11.5 192
D E F
6.27 5.31 3.54
O P Q
3.20 0.45 7.55
Proline Promass 80A, 83A
F G
E
K
J J
S
Q P
G H J
45 >50 81
R S T
2 x ∅ 6.5
8 × M5 20
G H J
1.77 >1.97 3.18
R S T
2 x ∅ 0.26
8 × M5 0.79
