Endress+Hauser Proline Promass 80A Technical Information page 29

Proline Promass 80A, 83A
Endress+Hauser
4-VCO-4-connection with mounting kit: DN 15 flange
Monting kit DN 15 flange EN 1092-1 (DIN 2501) PN 40: 1.4539/904L, Alloy C-22
DN PN
1 40
2 40
4 40
Loose flanges (not wetted) made of stainless steel 1.4404/316L
All dimensions in [mm]
Monting kit ½" flange (ASME): 1.4539/904L, Alloy C-22
DN ASME
1 Cl 150
1 Cl 300
2 Cl 150
2 Cl 300
4 Cl 150
4 Cl 300
Loose flanges (not wetted) made of stainless steel 1.4404/316L
All dimensions in [mm]
Monting kit DN 15 flange (JIS): 1.4539/904L, Alloy C-22
DN JIS
1 10K
1 20K
2 10K
2 20K
4 10K
4 20K
Loose flanges (not wetted) made of stainless steel 1.4404/316L
All dimensions in [mm]
Esc
-
+ E
+1.5 (+0.06)
L
–2.0 (–0.08)
L P Q
393 95 17.3
475 95 17.3
600 95 17.3
L P Q
393 88.9 15.7
393 95.2 15.7
475 88.9 15.7
475 95.2 15.7
600 88.9 15.7
600 95.2 15.7
L P Q
393 95 15.0
393 95 15.0
475 95 15.0
475 95 15.0
600 95 15.0
600 95 15.0
S
mm (inch)
R S LK
4 × Ø14 28 65
4 × Ø14 28 65
4 × Ø14 28 65
R S LK
4 × Ø15.7 17.7 60.5
4 × Ø15.7 20.7 66.5
4 × Ø15.7 17.7 60.5
4 × Ø15.7 20.7 66.5
4 × Ø15.7 17.7 60.5
4 × Ø15.7 20.7 66.5
R S LK
4 × Ø15 28 70
4 × Ø15 14 70
4 × Ø15 28 70
4 × Ø15 14 70
4 × Ø15 28 70
4 × Ø15 14 70
a0003184
di
1.1
1.8
3.5
di
1.1
1.1
1.8
1.8
3.5
3.5
di
1.1
1.1
1.8
1.8
3.5
3.5
29
