Endress+Hauser Proline Promass 80A Technical Information page 25

Proline Promass 80A, 83A
Endress+Hauser
Transmitter compact version, stainless steel
Dimensions in SI and US units
A
[mm] [inch]
225 225
Transmitter remote version, connection housing (II2G/zone 1)
A
A*
B
B*
Nicht-eigensichere
Stromkreise durch
IP40-Abdeckung geschützt
Non-intrinsically safe
circuits Ip40 protected
Boucles de courant
sans sécurité intrinsèque
protégées par Ip40
Dimensions in SI units
A A* B B*
265 242 240 217
* Blind version (without display)
All dimensions in [mm]
Dimensions in US units
A A* B B*
10.4 9.53 9.45 8.54
* Blind version (without display)
All dimensions in [inch]
A
B
[mm] [inch]
153
F ∅
C D E
8.6
206 186 178
(M8)
F ∅
C D E
0.34
8.11 7.32 7.01
(M8)
B
Esc
-
+ E
C
[mm]
153 168
C
D
r
Esc
– + E
G
H
G H J K
100 130 100 144
G H J K
3.94 5.12 3.94 5.67
a0002245
[inch]
168
a0006999
L M
170 348
L M
6.69 13.7
25
