Process connections in SI units
4-VCO-4-connection (welded)
4-VCO-4-connection: 1.4539/904L, Alloy C-22
DN
1)
1 290
1)
2 372
2)
2 372
1)
4 497
2)
4 497
1)
3A version can be supplied (Ra ≤ 0.4 μm/240 grit). Only for 1.4539/904L
2)
High-pressure version
All dimensions in [mm]
1/2" Tri-Clamp connection (welded)
½" Tri-Clamp connection / 3A version
DN L
1 296
2 378
4 503
1)
3A version (Ra ≤ 0.8 μm/150 grit. option: Ra ≤ 0.4 μm/240 grit)
All dimensions in [mm]
Esc
- + E
+1.5 (+0.06)
L
–2.0 (–0.08)
L
AF 11/16"
AF 11/16"
AF 11/16"
AF 11/16"
AF 11/16"
Esc
- +
E
+1.5 (+0.06)
L
–2.0 (–0.08)
1)
: 1.4539/904L
P
25
25
25
Proline Promass 80A, 83A
mm (inch)
P Q / di
mm (inch)
Q
9.5
9.5
9.5
Endress+Hauser
a0003165
1.1
1.8
1.4
3.5
3.0
a0003183
di
1.1
1.8
3.5
