Logging In and Out

Certain operator functions are passcode-protected at differ-
ent levels. This section describes the operator functions,
their default access level, and the login/logout procedure.
Table 1-2 Access Levels and Features
Access
Level
1
2
Passcode =
2000
3
Passcode =
3000
4
Passcode =
4000

Login/Logout Procedure

To perform any of the functions protected at Level 2 or
above, you must login to the panel using a passcode. After
completing a task at a certain access level, you should then
logout to return the access level to Level 1 to prevent unau-
thorized operation. When logged in at Level 2 or above and
no panel keys are pressed for more than 10 minutes, the
panel automatically returns the system to Level 1.
All passcodes consist of a 4-digit number. Logging in at
Level 4 causes a Service Mode trouble that may only be
cleared by restarting the panel.
To login, perform the following steps:
1.
Obtain the passcode information for the desired level.
2.
Press <MENU>
3.
Press <NEXT> until [Login/Logout] is displayed, then
press <ENTER>. A prompt similar to the following
appears.
Access: Level 1
<ENTER>=[Login]
4.
Press <NEXT> until [Login] is displayed, then press
<ENTER>. A prompt similar to the following appears.
Technical Manuals Online! - http://www.tech-man.com
Operation
Acknowledge, Silence, System Reset,
View Historical Logs,
View Point Information, Lamp Test
All Level 1 operations, plus:
Set Time/Date, Point Control,
Enable/Disable points
All Level 1 & 2 operations, plus:
Clear Historical Logs,
Clear Verification Tallies
Custom Label editing
WALKTEST
All Level 1, 2, & 3 operations, plus:
Programming,
Upload/Download
Access: Level 1
Passcode:
5.
Use the Keypad to enter the appropriate passcode.
6.
When the passcode is correct, press the <ENTER> key
to login.
A "Login Accepted" message, which indicates your current
access level, is displayed briefly upon a successful login
attempt. If you did not enter the appropriate Login passcode,
a "Login Invalid" screen appears.
To logout, perform steps 1-4 above, but select Logout
instead of Login.

Overview - Programming a Job

A job refers to the file containing all of the panel's program-
ming information. This manual describes the process
required to create a job from the front panel of the system.
Creating a job involves:
•
Setting the attributes of each IDC, NAC, and AUX
relay, including:
-
Function Type. Determines the way in which the
IDC, NAC, or relay operates (i.e., fire point, trouble
point, on til silence, etc.)
-
Custom Label. This is a 20-character label that
describes each zone, NAC, or relay.
-
Alarm Group. Allows inputs and outputs to be
associated into groups to implement selective sig-
naling applications. See "Alarm Groups" below.
•
Defining the attributes (phone numbers, account num-
bers, reporting format, etc.) of the panel's Digital Alarm
Communicator Transmitter (DACT). If the DACT will
not be used, programming consists of disabling the
DACT.
•
Programming the operation of the LEDs contained on
the panel and connected annunciators. Programming an
annunciator consists of identifying the point being mon-
itored by the LED and the mode (i.e., fire alarm, trou-
ble, etc.) that will trigger the LED to illuminate.
•
Setting values for the panel's system options, which are
pre-defined modes of operation with a range of settings
from which to choose. System Options define global
operations such as the time and date format, door drop
timers, and whether the city circuit is enabled, etc.
1-5
Chapter 1. Overview
