Dimensions
Weight
13.2 FreeSpeak II Beltpack
Beltpack Frequency Response
Beltpack Assignment-Select Buttons 2, used to edit beltpack menu
Number of Full-Duplex Audio Paths 4, with individual level control
Level/Talk Controls
Headset Connector
Headphone Impedance
Microphone Type
Input Level
Electret headphone voltage
Microphone and Headset Limiters Selectable in beltpack menu
Powering
Battery Charging
Battery Life
Range from Single FSII-TCVR-19
Transceiver/Antenna
Approx. dimensions
Weight (with batteries)
Page 179
User Guide | FreeSpeak II™ Base station version
1-RU unit, 44 x 483 x 312 mm (hwd)
(1.75 x 19.0 x 12.5 inches)
Approx. 4.5 Kg (10 lb).
100 Hz – 7.1 kHz
options
2 top-mounted rotary
encoders
XLR-4M, Clear-Com standard
32 ohm to 2000 ohm
Dynamic or electret, selectable in
beltpack menu
-70 to -40 dBu
2.3V
Li-Ion Battery, 3 AA alkaline cells
In unit, via supplied 5 way AC60 charger
Approximately 18 hours
500 m from transceiver/antenna in
line-of-sight conditions; 50 m indoors;
use multiple antennas for larger, custom
coverage areas
38 x 130 x 100 mm (dwh)
(1.5 x 5 x 3.75 inches)
Approx. 400g (9 oz).
