ClearCom FreeSpeak II Quick Start Manual

FreeSpeak II™
Quick Start Guide for the battery charger
A FreeSpeak II (FS II) battery charger (AC60) allows you to charge up to five FS II beltpacks simultaneously.
You can use it either as a drop-in charger for the whole beltpack, or you can charge separate beltpack Li-Ion
batteries (BAT60) in the charging slots provided. You can use the charger either as a desktop unit, or you can
mount it to a wall using an optional wall bracket.
For more information about the system see the FreeSpeak II User Guide.
1.

Installing the battery charger

1) Either mount the charger to a wall using the
optional wall bracket or leave on a desktop.
2) Connect the power supply to the power
connector.
Power
connector
Mounting
bracket
Support for optional
mounting bracket
2.

Charging the beltpack

The beltpack can use a rechargeable Li-Ion battery or
non-rechargeable AA batteries. The charger can charge
up to five Li-Ion batteries simultaneously.
Warning:
Only use the battery charger with the
supplied rechargeable batteries. If you use the
charger with any other batteries, serious damage or
injury could result.
Note: You can also recharge batteries by using a USB
cable.
1 399G108 Rev: B 09/04/14
Mounting
bracket
Optional wall-mounting bracket
